Chieftec
Reference: PPG-750-C
EAN: 0753263078896
Condition: New
€88.06
VAT included
Without tax: €72.77
  • 750W total power, 80 PLUS Gold certified
  • ATX 3.1 form factor, fully modular cabling
  • 135mm FDB fan for active cooling
  • 4x PCIe 6+2 pin and 1x 12+4 pin connectors
  • Black color, dimensions 150x150x85 mm
Share


Buy it now and receive it between Fri 2 and Tue 6 with GLS / UPS / DHL €5.99

Up to 3 years warranty 100% secure payment 14 days return

Regulatory approvals
Certification
80PLUS Gold
Ports and Interfaces
Peripheral (Molex) power connectors (4 pin)
3
ATX power connector (24 pins)
Yeah
Wiring type
Fully modular
CPU power connector (4 + 4 pins)
Yeah
PCI Express power connectors (6 + 2 pin)
4
EPS power connector (8-pin)
Yeah
Motherboard power cable length
60 cm
SATA power cable length
400
PCI Express power connector cable length (12+4 pin)
600 mm
Number of SATA power connectors
6
EPS power connector (4+4 pins)
Yeah
PCI Express power connectors (12+4 pin)
1
CPU power cable length
65 cm
Motherboard power supply
20+4 pin ATX
ATX power connector (20 + 4 pin)
Yeah
Peripheral power cable length (Molex)
400 mm
Design
Lightning
No
Product color
Black
Fan diameter
13.5 cm
Cooling type
Asset
Performance
ATX version
3.1
Use with
PC
Power supply unit (PSU) form factor
ATX
80 PLUS Certification
80 PLUS Gold
Bearing technology
FDB
Weight and dimensions
Depth
150 mm
Weight
1.96 kg
Height
85 mm
Broad
150 mm
Packaging
Package weight
2.43 kg
Energy control
Combined power (3.3 V)
100 W
AC input voltage
100 - 240 V
Maximum output current (+5V)
20 A
Total power
750 W
Combined power (+5 V)
100 W
Maximum output current (+3.3V)
20 A
AC input frequency
50/60 Hz
Maximum output current (-12V)
0.3 A
Power factor correction (PFC)
Asset
Maximum output current (+12 V1)
62.5 A

  • Brand
  • Reference
    PPG-750-C
  • In stock
    25 Items
  • Condition
    New
  • EAN13
    0753263078896
  • MPN
    PPG-750-C

  • Color
    Black

Brand Chieftec
Country Germany
Address of origin Koppersstr. 18 40549 Düsseldorf
EU responsible person CHIEFTEC Industrial Co., Ltd.
Address Weidehek 26, 4824 AS Breda, Netherlands
Email [email protected]
Phone 31765206540
