Gigabit single-mode media converter
- 1x 10/100/1000Mbps RJ45 copper port
- 1x 1000Base-LX SC single-mode fiber port
- Transmission distance up to 20km
- Auto MDI/MDIX on RJ45 port
- Plug-and-play, no configuration required
-
Interfaces: 1 x RJ45 Gigabit Ethernet (Auto MDI/MDIX, 10/100/1000 Mbps) + 1 x SC single-mode fibre (1310/1550 nm TX/RX in WDM), automatic half/full duplex negotiation.
-
Maximum distance: 10-20 km (9/125 μm fibre), optimal for point-to-point links between buildings or distant racks without repeaters.
-
Speed: 1000 Mbps full-duplex (2 Gbps bidirectional), IEEE 802.3ab/z compliant, store-and-forward with CRC filtering for packet integrity.
-
WDM technology: Transmits/receives at different wavelengths (1310/1550 nm) over a single fibre, saving 50% cabling vs. traditional duplex.
-
Power: DC 5V external (1A, adapter included), power consumption <4 W, fanless design with LEDs (power/LINK/ACT/FX) for visual diagnostics.
-
Physical design: Compact metal/plastic (~100x70x30 mm, 0.3-0.5 kg), DIN rail/desktop mounting, temperature 0-70°C for protected outdoor use.
-
Indicators: LEDs for Power, Link/Act (TP/FX), speed and FDX, facilitating troubleshooting in complex network chains.
-
Compatibility: UTP Cat5e/6 up to 100m + SM fibre, interoperable with D-Link DES-1005D, MikroTik hAP Lite or Cudy Mesh Gigabit switches.
-
Certifications: CE/FCC/RoHS typical, MTBF >100,000 hours for reliable 24/7 deployments.
-
Brand
-
ReferenceMC210CS
-
ConditionNew
-
EAN131210002611053
-
MPNMC210CS
| Brand | TP-LINK |
|---|---|
| Country | Spain |
| Address of origin | Am Trippelsberg 100, Dusseldorf, DE, 40589 |
| EU responsible person | TP-Link Technologies Co., Ltd. |
| Address | Feldring 9, Hofheim am Taunus, Germany, 65719 |
| [email protected] | |
| Phone | 34912000727 |
