Lindy DST-Pro Docking Station Anthracite

The next-generation USB4 DST-Pro is a high-performance, multifunctional solution for connecting laptops, tablets or mobile phones to a variety of interfaces including one 8K 30Hz DisplayPort or HDMI display or two displays simultaneously at 4K 60Hz* , using a single cable. It also supports 4K 120Hz video resolutions, making it the ideal tool for high-resolution video editing or game streaming.

This docking station offers a host of ports capable of connecting your devices to your workflow.With SuperSpeed USB and Ethernet, you can expect a blazing-fast experience and enhanced productivity, while card readers (SD and Micro-SD) let you expand your storage capacity beyond that of your device. Through a single USB-C cable, connect to multiple SuperSpeed 10Gbps USB Type-A or Type-C ports, a 3.5mm headphone combo jack, Gigabit Ethernet, (micro)SD card slots, DisplayPort, and HDMI .

The USB4 docking station also supports Power Delivery 3.0 up to 100W to charge the connected laptop.A power supply is not included.The dock can be used with the power supply supplied with the laptop or a power supply can be purchased separately.

This USB4 laptop docking station is compatible with computers that have the USB Type-C port supporting DisplayPort 1.4 Alternate Mode, i.e. USB4 or USB 3.2, as well as Thunderbolt 3 or TB4 host devices.

• Connect an HDMI and/or DisplayPort display, USB peripherals, and power through a single cable
• Supports 8K 30Hz single display or 4K 60Hz dual display (MST)*
• Integrated 4-Port SuperSpeed USB 10 Gbps Hub (3 x Type A, 1 x Type C)
• USB power delivery with capacity up to 100 W

Specifications

• Interfaz: USB tipo C a 6x USB tipo A / 1x USB tipo C / 1x RJ45 / 1x DisplayPort / 1x HDMI / 1x SD y 1x MicroSD / 1x audio de 3,5 mm / 1x USB tipo C PD
• Interface standard: USB4 (upstream port);4x USB 3.2 / 3.1 Gen 2 (3x Type A, 1 and Type C) / 3x USB 2.0 (Type A), Gigabit LAN, DP 1.4, HDMI 2.1, SD/TF 3.0 (max. 1 Gbps), 3.5 Audio mm (combined)
• Supported Bandwidth: 10 Gbps, 10/100/1000 Mbps
• Maximum input resolution: 7680x4320@60Hz
• Maximum output resolution:
  • Single display: 7680x4320 30Hz, 3840x2160 120Hz
  • Dual displays: 3840x2160 60Hz
• Chipset:VL830, VMM6210, AX88179A, GL3224, VL105
• Compatibility: USB4/Type C or Thunderbolt 3/4 equipped computers with support for DisplayPort Alternate Mode
• Power Delivery: PD 3.0 up to 100W (20V 5A)
• HDCP Compatibility: HDCP 2.2
• Supported Audio: Audio 1-32 CH LPCM 192KHz, HBR up to 1536 KHz, IEC 61937 compressed audio, Dolby ATMOS, DTS:X format
• Separate audio ports: 1 x 3.5mm audio combo port
• Special Features: DisplayPort Alternate Mode, 3 USB Gen 2 Type A ports for battery charging 1.2 (total current limit is 2.3A), MST for Windows compatible, Simultaneous card reading (microSD) support, PXE preboot execution) and Wake on LAN (WOL) support

connectors

• Inputs: 1 x USB Type-C (female)
• Outputs: ?6x USB type A (female), 1x USB type C (female), 1x RJ45 (female), 1x DisplayPort (female), 1x HDMI (female), 1x SD (female), 1x MicroSD (female), 1x 3.5 mm audio jack
• Power: 1 x USB Type-C (female) PD port

physical properties

• Dimensions W x D x H: 129 x 69.5 x 48 mm (5.08 x 2.74 x 1.89 in)
• Shell material: aluminum alloy
• Net Weight: 0.3kg (0.66lbs)
• Operating temperature: 0? - 40°C (32°F - 104°F)
• Storage temperature: -10 °C - 70 °C (14 °F - 158 °F)
• Humidity: 10 - 90% RH (non-condensing)
• Power requirements: 20W
• Colour: Anthracite

Package Contents

• USB4 Laptop Docking Station
• 0.8m USB4 Type C Male to Male Cable
• Lindy's Handbook
