Zebra
Reference: DS9308-SR4U2100AZE
Condition: New
€134.06
VAT included
Without tax: €108.99
The Zebra DS9308-SR is a fixed barcode reader supporting 1D and 2D scanning with LED sensor technology. It features a compact design in black, measuring 86mm wide, 145mm high, and 83mm deep, weighing 318g. This device operates efficiently within 0-50°C and supports various barcode types including Codabar, QR Code, and Data Matrix. Connectivity is wired via USB and RS-232 interfaces, making it ideal for diverse scanning applications.

Buy it now and receive it between Wednesday 7 October and Tuesday 13 October with GLS o Correos Express España €20.23

In stock
Share

Up to 3 years warranty 100% secure payment 14 days return

Performance
Certification
EN 50581:2012, RoHS 2011/65/EU (2015/863) - EN 50581:2012, IEC 63000, REACH 1907/2006, IEC 62368-1 2nd ed. EN 62368-1:2014/AC:2015, UL/IEC 60950-1, 2nd ed. CAN/CSA C22.2 No.60950-1, 2nd ed. IEC 62471:2006 (Ed.1.0), EN 62471:2008 (LED), FCC 47 CFR Part 15B, ICES-003, EN55032, EN55024, EN55035, VCCI, and SABS
Product color
Black
IP Code (International Protection)
IP52
Weight and measurements
Broad
86mm
Height
145mm
Depth
83mm
Weight
318g
Environmental conditions
Storage temperature range
-40 - 70°C
Relative humidity range for operation
5 - 95%
Operating temperature range
0 - 50°C
Exploration
Scan type
1D/2D
Guy
Fixed barcode reader
Optical sensor resolution (W x H)
1280 x 800 Pixels
Sensor type
LED
Linear (1D) barcodes supported
Codabar, MSI, GS1 DataBar, UPC, Code 39, EAN-13, Code 128, Code 11, Code 93
2D (arrays and stacked) barcodes supported
MaxiCode, Micro QR Code, Han Xin, QR Code, Composite Barcodes, MicroPDF417, TLC-39, Dot Code A, PDF417, Data Matrix, Aztec Code
Reading tilt angle
-60 - 60 Ω
working distance
66cm
Light levels (direct sunlight)
0 - 107700 lx
Power control
Feeding
USB, RS-232
Input voltage
5.5V
Ports and Interfaces
Standard interface
RS-232, USB
Connectivity technology
Wired
Logistics data
Harmonization System (HS) Code
84716070

  • Brand
  • Reference
    DS9308-SR4U2100AZE
  • In stock
    54 Items
  • Condition
    New
  • MPN
    DS9308-SR4U2100AZE

  • Colour
    Black

Brand Zebra
Country USA
Address of origin 3 Overlook Point, Lincolnshire, Illinois 60069
EU responsible person Zebra Technologies Corp.
Address Calle Martinez Villergas, 52 Bloque C Madrid 28027
Email [email protected]
Phone 34911237350
