Thermaltake Toughpower GF1 A-RGB 80 Plus Gold 650W Modular - Fuente/PSU

Electrical specifications

• Total power 650W continuous (peak 780W), single rail +12V (54.2A / 650W) with +3.3V/+5V combined 120W (22A each), +5Vsb 3A, -12V 0.3A; ripple <30mV on all rails.

• 80 PLUS Gold (115V input), active PFC, universal input 100-240V 10A 50-60Hz, hold-up time >16 ms, ultra-narrow voltage regulation ±2% (better than Intel standard ±5%).

Design and modularity

• Compact ATX format (150 x 86 x 160 mm), fully modular with black flat cables: 1x 24-pin ATX, 2x 4+4-pin EPS12V, 4x 6+2-pin PCIe, 8x SATA, 4x Molex; Zero Cable design for clean management.

• 140 mm Riing Duo RGB fan (500-1400 RPM, <26.2 dBA) with 18 addressable ARGB LEDs and Smart Zero Fan (fanless <30% load).

Lighting and timing

• Side ARGB (18 LEDs, 16.8M colours) compatible with ASUS Aura Sync, MSI Mystic Light, Gigabyte RGB Fusion, ASRock Polychrome via 3-pin 5V ARGB header; analogue driver included.

• Translucent side panels for intense lighting effects; Zero Fan switch on rear panel.
