The Uni-T UT276A+ is a professional-grade clamp meter designed for electricians and technicians. It features true RMS measurement for accurate readings on non-linear loads, and can measure AC/DC current up to 1000A without breaking the circuit. The large jaw opening accommodates conductors up to 30mm in diameter.
In addition to current, the UT276A+ measures AC/DC voltage up to 600V, resistance, capacitance, frequency, and temperature (with type-K thermocouple). It includes a backlit LCD display, data hold, and auto power-off. Safety rated CAT III 600V, it is suitable for industrial and commercial environments.
| DC Current (A) | 0-1000A |
| AC Current (A) | 0-1000A (True RMS) |
| DC Voltage (V) | 0-600V |
| AC Voltage (V) | 0-600V (True RMS) |
| Resistance (Ω) | 0-60MΩ |
| Capacitance (F) | 0-60mF |
| Frequency (Hz) | 0-10MHz |
| Temperature (°C/°F) | -40°C to 1000°C (-40°F to 1832°F) |
| Jaw Opening | 30mm |
| Safety Rating | CAT III 600V |
| Display | LCD with backlight |
| Power Supply | 9V battery (6F22) |
