The UNI-T UT677A+ is a professional-grade digital multimeter designed for electricians and technicians. It features 6000 counts true RMS measurement for accurate readings on non-sinusoidal waveforms. The meter offers a wide range of functions including AC/DC voltage up to 1000V, resistance up to 40MΩ, capacitance up to 100mF, frequency, duty cycle, and temperature measurement via a thermocouple probe.
Safety is prioritized with features like non-contact voltage (NCV) detection, low impedance (LoZ) mode to eliminate ghost voltages, and overload protection. The large backlit LCD display and auto-ranging capability make it easy to use in various environments. The UT677A+ is CAT III 1000V and CAT IV 600V rated, ensuring reliability in demanding electrical testing scenarios.
| Display Counts | 6000 |
| True RMS | Yes |
| AC Voltage Range | 0.1mV to 1000V |
| DC Voltage Range | 0.1mV to 1000V |
| Resistance Range | 0.1Ω to 40MΩ |
| Capacitance Range | 0.01nF to 100mF |
| Frequency Range | 0.01Hz to 10MHz |
| Temperature Range | -40°C to 1000°C |
| NCV Detection | Yes |
| LoZ Mode | Yes |
| Safety Rating | CAT III 1000V / CAT IV 600V |
| Power Supply | 9V battery (6F22) |
| Brand | UNI-T |
|---|---|
| Country | Poland |
| Address of origin | Bystrzycka 69C, 54-215 Wrocław |
| EU responsible person | GOTRONIK PPHU |
| Address | Bystrzycka 69C, 54-215 Wrocław |
| [email protected] | |
| Phone | +34 912844705 |
