5-30 ext. micrometer type A
Reference:
3220-30
EAN:
6928640308147
Condition:
New
Price:
€78.55
VAT included
Without tax:
€63.87
- Range: 5-30mm (0.2-1.2in)
- Resolution: 0.01mm (0.0005in)
- Measuring faces: Carbide-tipped
- Spindle: Ø6.5mm, ground thread
- Frame: Insulated, with ratchet stop
5-30 EXT. MICROMETER TYPE A
The INSIZE 3220-30 is a high-precision external micrometer designed for accurate measurement of external dimensions. With a measuring range of 5-30mm and a resolution of 0.01mm, it is ideal for use in machining, quality control, and inspection applications. The micrometer features carbide-tipped measuring faces for durability and wear resistance, ensuring long-term accuracy.
Equipped with a ratchet stop mechanism, the 3220-30 provides consistent measuring force for repeatable results. The insulated frame minimizes heat transfer from the hand, reducing thermal expansion errors. The spindle has a ground thread for smooth operation, and the clear, easy-to-read graduations on the thimble and sleeve facilitate quick readings.
| Brand | INSIZE |
| Model | 3220-30 |
| Type | External Micrometer Type A |
| Range | 5-30mm (0.2-1.2in) |
| Resolution | 0.01mm (0.0005in) |
| Measuring Faces | Carbide-tipped |
| Spindle Diameter | 6.5mm |
| Frame | Insulated, with ratchet stop |
| Standards | DIN 863, JIS B 7502 |
-
