iggual GES16000 Offline UPS - 1600VA / 900W - Black (8435364318324)
The iggual GES16000 (IGG318324) is a professional-grade uninterruptible power supply (UPS) engineered to provide reliable backup power and electrical protection for workstations and network hardware. This hardware utilizes Offline (Standby) technology, which monitors the incoming AC utility power and instantaneously switches to battery power during a blackout or significant voltage drop. It is equipped with a high-capacity 1600VA internal battery system capable of supporting a 900W load, providing sufficient runtime for the safe shutdown of connected computer systems. The device features integrated Automatic Voltage Regulation (AVR) to stabilize fluctuating voltages without depleting the battery, as well as high-energy surge protection to safeguard sensitive internal components from transient electrical spikes. Its compact tower chassis includes an intuitive LED interface for real-time status monitoring of power conditions and battery levels.
Technical Specifications
* Model: GES16000
* Part Number: IGG318324
* Capacity: 1600 VA / 900 W
* Technology: Offline (Standby) with AVR
* Input Voltage Range: 145V - 290V AC
* Output Voltage (Battery Mode): 220V - 240V AC
* Frequency: 50/60 Hz (Auto-sensing)
* Transfer Time: Typical 2–6 ms
* Waveform Type: Simulated Sine Wave
* Battery Type: 2x 12V / 9Ah Lead-Acid (Sealed)
* Recharge Time: 4–6 hours to 90% capacity
* Output Sockets: 4x Schuko (Battery backup and surge protection)
* Protection: Short circuit, Overload, Discharge, and Overcharge
* Dimensions: 345 x 146 x 162 mm
Key Features
* High-Capacity Battery Backup: Provides a 1600VA power reservoir, ensuring operational continuity for high-load hardware during utility power failures and preventing data loss.
* Integrated Automatic Voltage Regulation (AVR): Features an internal boost and buck circuit that corrects minor voltage fluctuations to a safe range, extending the operational lifespan of the internal lead-acid batteries.
* Cold Start Operational Capability: Engineered with the ability to initiate power delivery directly from the battery in the absence of an AC utility source, facilitating emergency hardware testing.
* Advanced Circuit Protection Suite: Incorporates industrial-grade fuses and electronic monitoring to protect connected peripherals from overloads, short circuits, and high-frequency electrical noise.
* Intelligent Battery Management: Utilizes a sophisticated charging algorithm that prevents deep discharge and overcharging, maintaining the structural integrity of the 12V/9Ah cells for long-term reliability.
