Startech Mini USB 3.1 Gen 2 Type-C docking station (10 Gbps) with HDMI or DisplayPort video output (4K at 60 Hz) or VGA (1080p)

The Startech Mini USB 3.1 Gen 2 Type-C docking station is a compact, portable adapter that turns a single USB-C port into a full workstation connection. With a USB 3.2 Gen 2 (3.1 Gen 2) Type-C host interface and 10 Gbit/s data transfer speed, it adds video output, USB expansion and wired Gigabit Ethernet in a small black and grey unit measuring 90 x 90 x 32.5 mm and weighing 201 g.

Connect a single display through one of three video outputs: HDMI, DisplayPort or VGA. Digital output reaches up to 3840 x 2160 (4K) at 60 Hz on compatible hosts, while VGA supports up to 1080p. The built-in USB hub provides two USB-A ports and one USB-C downstream port, all rated for USB 3.2 Gen 2 (3.1 Gen 2) speeds up to 10 Gbps, plus a Gigabit Ethernet RJ-45 port for wired networking at 10/100/1000 Mbit/s.

The dock can run bus-powered or with an external USB-C power adapter, supporting USB Power Delivery 3.0 pass-through up to 75 W with 15 W reserved for the adapter. An integrated 25 cm cable gives extra reach and reduces strain on ports in 2-in-1 devices such as iPad Pro and Surface Pro 7. It works with Windows, macOS, iPadOS, Chrome OS and Android, and is compatible with ultrabooks, Chromebooks, tablets and Thunderbolt 3 laptops from brands such as HP, Dell, Lenovo and MacBooks (Intel and M1/M2).

Características principales

• USB 3.2 Gen 2 (3.1 Gen 2) Type-C host interface with 10 Gbit/s transfer speed
• Three video outputs: 1x HDMI, 1x DisplayPort, 1x VGA (D-Sub)
• Digital resolution up to 3840 x 2160 (4K) at 60 Hz on compatible hosts; VGA up to 1080p
• Integrated USB hub: 2x USB-A and 1x USB-C downstream ports at up to 10 Gbps
• Gigabit Ethernet RJ-45 port (10/100/1000 Mbit/s), IEEE 802.3ab/i/u
• USB Power Delivery 3.0 pass-through up to 75 W (15 W reserved for the adapter)
• Compact 90 x 90 x 32.5 mm body, 201 g, with 25 cm integrated cable

Specifications

Preguntas frecuentes

What video outputs does this docking station offer?

It provides one HDMI port, one DisplayPort and one VGA (D-Sub) port, so you can connect a single display using any of the three output types.

What resolution can I get?

Digital output supports up to 3840 x 2160 (4K) at 60 Hz on compatible hosts; VGA output supports up to 1080p.

Does it add USB ports and wired networking?

Yes. It includes an integrated USB 3.2 Gen 2 hub with two USB-A ports and one USB-C downstream port at up to 10 Gbps, plus a Gigabit Ethernet RJ-45 port supporting 10/100/1000 Mbit/s.

Which operating systems are supported?

It works with Windows, macOS (Mac OS X 10.12 Sierra through 13.0 Ventura), iPadOS/iOS, Android and ChromeOS.

Es para ti si...

• You need a compact, portable dock for a USB-C ultrabook, Chromebook, tablet or Thunderbolt 3 laptop
• You want HDMI, DisplayPort or VGA video output from a single USB-C port
• You need extra USB-A and USB-C ports plus wired Gigabit Ethernet
• You value a small 90 x 90 x 32.5 mm design with a 25 cm integrated cable
