The AVer U50+ is a document camera designed for classroom and remote teaching. It combines an 8 MP CMOS sensor with a flexible arm and a single USB connection for both power and data, so you can set it up and start presenting without extra equipment. It suits teachers who need to show printed material, objects or themselves on screen, whether in a classroom or in a hybrid lesson.
Highlights
- 8 MP CMOS sensor with a 1/3.2" optical format: captures still images at up to 3264 x 2448, so printed text and fine detail stay legible when projected.
- Video recording at up to 60 fps: movement on screen stays smooth, which helps when you demonstrate a process or write live.
- Shooting area of 420 x 315 mm and support for documents up to A3: you can show a full worksheet or a large diagram without repositioning it.
- USB 2.0 interface with USB power at 5 V and 0.5 A: one cable handles both connection and power, keeping setup simple.
- Flexible arm that bends to any angle, plus a freeze-image function: present materials from the angle you need and hold a frame on screen while you talk.
- Built-in anti-flicker and a 3-level LED light: adapt to different lighting conditions and keep the image steady under artificial light.
- Compact body of 259 x 165 x 39.3 mm and 1.52 kg: easy to move between rooms and store when not in use.
Technical specifications
Camera
| Effective sensor resolution | 8 MP |
| Optical sensor size | 25.4 / 3.2 mm (1 / 3.2") |
| Sensor type | CMOS |
| Supported graphics resolutions | 3264 x 2448 |
| Video recording | Yes |
| Maximum frame rate | 60 fps |
| Image freeze | Yes |
Lens system
| Shooting area (WxD) | 420 x 315 mm |
Ports & interfaces
Technical details
| Document size (max) | A3 |
| Product colour | Black |
| Anti-flicker | Yes |
| Country of origin | China |
Power
| Power supply type | USB |
| Operating voltage | 5 V |
| Operating current | 0.5 A |
Weight & dimensions
| Width | 165 mm |
| Depth | 39.3 mm |
| Height | 259 mm |
| Weight | 1.52 kg |
| Dimensions folded (WxDxH) | 259 x 165 x 39.3 mm |
Packaging data
| Quantity per pack | 1 pc(s) |
| Package width | 352 mm |
| Package depth | 252 mm |
| Package height | 434 mm |
| Package weight | 2.24 kg |
Packaging content
Manufacturer technical data.
Frequently asked questions
What do I need to connect it?
Just a USB cable, which is included. The U50+ uses USB 2.0 for data and draws its power from the same connection at 5 V and 0.5 A, so there is no separate power supply to carry around.
What size of document can I show?
The shooting area is 420 x 315 mm and the camera supports documents up to A3. That covers full pages, textbooks and larger printed materials within that area.
Can I use it when the room is dark?
Yes. It has a built-in 3-level LED light that you adjust with a button on the side of the camera head, and anti-flicker is included to help keep the image stable under artificial lighting.
What resolution and frame rate does it offer?
The sensor is 8 MP CMOS with an effective resolution of 8 MP. Still images are captured at up to 3264 x 2448, and video recording runs at a maximum of 60 fps. A freeze-image function is also available.
