ALLNET USV 600VA Line-Interactive, USB, LCD-Display

This is an ALLNET ALL90600T UPS of 600 VA, 360 W, line-interactive technology, with LCD screen and USB port for monitoring, designed to protect one or more desktop PCs, a small NAS, or network electronics against power outages and voltage spikes.

Power and Technology

• Capacity of 600 VA / 360 W, suitable for 1 PC with monitor and light peripherals or a small NAS/NAS.

• Line-interactive topology with automatic voltage regulation (AVR), which corrects micro-outages, surges, and voltage drops without consuming battery.

Approximate Runtime

• Typical runtime: about 22 minutes at 25% load, 8 minutes at 50%, 1 minute at 75%, and about 30 seconds at 100% (360 W).

• Sufficient to save work, properly shut down equipment, or overcome micro-outages and very brief voltage drops.

Connections and Monitoring

• 4 IEC C13 outlets protected by battery and surge, with IEC C14 input; also includes 2 RJ-11 ports to protect the telephone/DSL line depending on the model.

• USB type B port and included PowerShut Plus software to monitor the UPS status and schedule automatic system shutdown.

Design and Use

• Compact tower format (approximately 142 x 105 x 300 mm, 4.4 kg), black PVC case with IP20 protection rating, intended for indoor use (0-40 °C, 0-90% RH).

• Backlit LCD screen showing load, battery level, input/output voltage, and fault/overload status.
