ZEBRA Charging Base CR40-3S4T-TC2-G
- Compatible with Zebra TC2 series mobile computers
- 4-slot simultaneous charging capability
- Input: 12V DC, 3.0A via power adapter
- Output: 5.2V DC, 2.0A per slot
- Dimensions: 320 x 200 x 85 mm
ZEBRA Charging Base CR40-3S4T-TC2-G
The Zebra CR40-3S4T-TC2-G is a multi-slot charging base designed for the Zebra TC2 series of rugged mobile computers. It allows simultaneous charging of up to four devices, making it ideal for high-uptime environments such as retail, logistics, and warehousing. The base features a compact footprint and robust construction to withstand daily use in demanding settings.
Each charging slot delivers a regulated 5.2V DC at 2.0A, ensuring fast and safe charging for the TC2 series batteries. The base communicates with the device to optimize charging cycles and prevent overcharging. It includes LED indicators for each slot to show charging status. The CR40-3S4T-TC2-G is powered by an external 12V DC adapter (sold separately) and supports pass-through data synchronization when connected to a host computer via USB.
| Compatibility | Zebra TC2 series (TC20, TC25, TC26) |
| Number of Slots | 4 |
| Input Voltage | 12V DC, 3.0A |
| Output per Slot | 5.2V DC, 2.0A |
| Charging Time | Approx. 4 hours for standard battery |
| LED Indicators | Red (charging), Green (complete) |
| Data Sync | USB 2.0 (via host connection) |
| Dimensions (W x D x H) | 320 x 200 x 85 mm |
| Weight | 1.2 kg |
| Operating Temperature | 0°C to 40°C |
| Material | Polycarbonate/ABS blend |
-
Brand
-
ReferenceCR40-3S4T-TC2-G-02
-
In stock3 Items
-
ConditionNew
-
MPNCR40-3S4T-TC2-G-02
| Brand | Zebra |
|---|---|
| Country | USA |
| Address of origin | 3 Overlook Point, Lincolnshire, Illinois 60069 |
| EU responsible person | Zebra Technologies Corp. |
| Address | Calle Martinez Villergas, 52 Bloque C Madrid 28027 |
| [email protected] | |
| Phone | 34911237350 |
