The dBTechnologies KL 10 is a compact active column loudspeaker designed for portable PA and installation applications. It features a 10-inch neodymium woofer and a 1-inch compression driver, delivering a maximum SPL of 130 dB. The built-in 400W RMS Class-D amplifier ensures efficient power delivery, while the integrated DSP provides preset equalization and protection.
The KL 10's lightweight polypropylene cabinet and ergonomic handles make it easy to transport and set up. The rotatable horn allows flexible horizontal or vertical mounting, and the M10 rigging points enable flying or bracket installation. With a frequency response of 55 Hz to 20 kHz, this speaker is suitable for live sound, speech reinforcement, and background music.
| Type | Active 2-way column loudspeaker |
| Woofer | 10" neodymium, 2.5" voice coil |
| HF Driver | 1" compression driver, 1.4" exit |
| Amplifier | Class-D, 400W RMS (800W peak) |
| Frequency Response | 55 Hz - 20 kHz (-10 dB) |
| Max SPL | 130 dB |
| Dispersion | 90° x 60° (rotatable horn) |
| Crossover | Active, 2.2 kHz |
| DSP | Presets: Flat, Music, Speech, Boost |
| Inputs | 1x XLR/TRS combo, 1x XLR link output |
| Enclosure | Polypropylene, black |
| Rigging | 4x M10 points, 35mm pole mount |
| Dimensions (HxWxD) | 530 x 320 x 300 mm |
| Weight | 12.5 kg |
| Brand | dBTechnologies |
|---|---|
| Country | Italy |
| Address of origin | Via Brodolini, 8, Loc. Crespellano, 40053 Valsamoggia (BO), Italy |
| EU responsible person | AEB INDUSTRIALE s.r.l. |
| Address | Via Brodolini, 8, Loc.Crespellano, 40053 Valsamoggia (BO) |
| [email protected] | |
| Phone | +39 051 96 98 70 |
