Huawei CloudEngine S5735I-S8T4SN-V2 Industrial DIN Rail Switch 8x GE 4x SFP Fanless
S5735i-s8t4sn-v2
The HUAWEI S5735i-s8t4sn-v2 is a compact managed switch designed for enterprise access and aggregation layers. It features 8 Gigabit Ethernet copper ports and 4 SFP fiber uplinks, providing flexible connectivity for small to medium networks. With a switching capacity of 24 Gbps and a forwarding rate of 17.9 Mpps, it ensures high-performance data forwarding. The fanless design makes it ideal for noise-sensitive environments like offices and classrooms.
This switch supports advanced Layer 2 features including VLAN, STP, link aggregation, and IGMP snooping. It also offers enhanced security with ACLs, port security, and DHCP snooping. The S5735i-s8t4sn-v2 is easy to manage via CLI, web GUI, or SNMP, and supports stacking for scalability. Its compact size and low power consumption make it a cost-effective solution for edge deployments.
| Ports | 8 x 10/100/1000BASE-T, 4 x 1000BASE-X SFP |
| Switching Capacity | 24 Gbps |
| Forwarding Rate | 17.9 Mpps |
| MAC Address Table | 16K |
| VLAN | 4K VLANs |
| Dimensions (W x D x H) | 250 x 180 x 43.6 mm |
| Weight | 1.5 kg |
| Power Supply | AC 100-240V, 50/60Hz |
| Power Consumption | ≤ 15W |
| Operating Temperature | 0°C to 45°C |
| Cooling | Fanless |
| Brand | HUAWEI |
|---|---|
| Country | China |
| Address of origin | G1, Huawei Industrial Base, Bantian, Distrito Longgang, Shenzhen 518129 |
| EU responsible person | Huawei Technologies Co., Ltd. |
| Address | Huawei Technologies Düsseldorf GmbH, Hansaallee 205, Düsseldorf, Germany, 40549 |
| [email protected] | |
| Phone | 4921197519400 |
