Asus Rack Platform (1U) Intel RS700-E11-RS4U

Main Technical Specifications

• Processors: Compatible with up to 2 Intel Xeon Scalable 5th generation CPUs (socket LGA4677)

• Memory: 32 DDR5 4800/4400 MHz modules, supporting large RAM capacity

• Storage:

  • 4 x 3.5" hot-swap 3.5" bays (NVMe/SATA/SAS)

  • 2 M.2 slots (for SSD storage)

  • SAS expansion requires additional controller card

• Expansion:

  • 4 PCIe 5.0 slots (1 of which supports dual slot GPU)

  • 1 OCP 3.0 slot

• Networking:

  • Optional: 4±1 GbE (Intel I350-AM4) or 2±10 GbE (Intel X710-AT2)

  • 1 LAN dedicated management

• Cooling: 9 fans and advanced dissipation solutions

• Power supply: 2 redundant power supplies (1+1), 1200W/1600W 80 PLUS Platinum/Titanium

• Form factor: 1U rack (44mm high, 439.5mm wide, 842.5mm deep, 22.6 kg)

Functionality

The server is focused on critical tasks such as virtualisation, AI, centralised storage, and scientific computing, allowing flexible storage installations, high connectivity and next-generation PCIe expansion for GPUs and accelerators.
