Reversible magnetic strike JS-1504N
- Operating voltage: 12V/24V DC
- Current draw: 500mA at 12V, 250mA at 24V
- Holding force: 1500N (337 lbs)
- Fail-secure or fail-safe selectable
- Stainless steel faceplate, reversible for left/right hand doors
Reversible magnetic strike JS-1504N
The JS-1504N is a versatile electromagnetic door strike designed for access control systems. It features a reversible design that allows installation on both left and right hand doors without additional hardware. The strike operates on 12V or 24V DC, drawing 500mA at 12V and 250mA at 24V, providing a holding force of 1500N (337 lbs). Its fail-secure or fail-safe mode can be selected via a jumper, making it suitable for various security requirements.
Constructed with a stainless steel faceplate and a robust electromagnetic coil, the JS-1504N ensures reliable locking and long service life. The strike is compatible with standard door frames and can be used with most access control panels. Its compact size and easy installation make it a popular choice for commercial and residential access control applications.
| Brand | JS |
| Model | JS-1504N |
| EAN | 5905496920601 |
| Type | Reversible magnetic strike |
| Operating Voltage | 12V/24V DC |
| Current Draw | 500mA @12V, 250mA @24V |
| Holding Force | 1500N (337 lbs) |
| Fail Mode | Selectable fail-secure/fail-safe |
| Faceplate Material | Stainless steel |
| Reversible | Yes, for left/right hand doors |
| Dimensions | 150 x 25 x 30 mm (approx.) |
-
