ROGER RUD-4-DES Proximity Reader
- Supports ISO/IEC 14443A MIFARE Classic and EM 125 kHz transponders
- Reading range up to 4 cm depending on card type
- Reading time approximately 200 ms
- Relay output 1A/30V
- Operating temperature +5 to +45 ºC, humidity 0–95% non-condensing
The ROGER saskarne RUD-4-DES is a high-quality proximity reader designed for access control applications. It supports reading transponders operating at EM 125 kHz and 13.56 MHz MIFARE Classic standards (ISO/IEC 14443A), compatible with EM 4100/4102. The device is powered directly via USB (5 VDC) and features a relay output rated at 1A/30V.
With a reading range of up to 3 cm for ISO MIFARE Classic cards and up to 4 cm for EM 125 kHz cards in optimal positions, it ensures quick and reliable identification with an approximate reading time of 200 milliseconds. The reader operates efficiently within a temperature range of +5 to +45 ºC and tolerates relative humidity from 0 to 95% without condensation.
Compact in size (11 x 10.5 x 14 mm) and weighing 0.84 kg, the RUD-4-DES is suitable for various installation environments. It is ideal for integration into access control systems requiring secure and fast transponder reading capabilities.
-
Brand
-
Reference17634
-
In stock4 Items
-
ConditionNew
-
EAN135907608963704
-
MPN17634
| Brand | Roger |
|---|---|
| Country | Poland |
| Address of origin | Gościszewo 59, 82-400 Sztum |
| EU responsible person | Roger sp. z o.o. sp. k. |
| Address | Gościszewo 59, 82-400 Sztum |
| [email protected] | |
| Phone | +34 912844705 |
