SATEL KNX 2-channel blind actuator 230V AC KNX-BSA12H
- 2 independent channels for blind/shutter control
- 230V AC motor output, 10A per channel
- KNX bus powered (no additional power supply needed)
- DIN rail mount (4 modules wide)
- Manual override buttons on device
SATEL KNX 2-channel blind actuator 230V AC KNX-BSA12H
The SATEL KNX-BSA12H is a compact 2-channel blind actuator designed for controlling 230V AC blinds, awnings, roller shutters, and similar motorized devices via the KNX bus. Each channel can independently drive a motor up to 10A, with built-in overload and short-circuit protection. The device is powered directly from the KNX bus, eliminating the need for an external power supply, and features manual override buttons for local operation.
Installation is straightforward with a DIN rail mount (4 modules wide). The actuator supports both individual and group addressing, and can be configured via ETS software for various functions such as position feedback, slat adjustment, and scene control. Its robust design ensures reliable operation in residential and commercial building automation systems.
| Number of channels | 2 |
| Motor voltage | 230V AC |
| Max. current per channel | 10A |
| Power supply | KNX bus (30V DC) |
| Mounting | DIN rail (4 modules) |
| Manual control | Yes, via buttons |
| Protection | Overload, short-circuit |
| Operating temperature | -5°C to +45°C |
| Dimensions (HxWxD) | 90 x 72 x 64 mm |
| Weight | 0.15 kg |
-
