Equip 327316 Premium 16-Port Cat.5e Shielded Patch Panel 19" 1U Light Grey RJ45 Gold

Equip 16-Port Cat.6 Unshielded Patch Panel - Black (4015867225981)

The Equip 327316 (133461) is a professional-grade high-density network termination module engineered to provide centralized cable management within 19-inch rack infrastructure. This hardware features a 16-port Cat.6 UTP (Unshielded Twisted Pair) architecture, designed to support high-bandwidth data transmission up to 1000 Mbps at a frequency of 250 MHz. The internal architecture utilizes 180-degree LSA-style termination blocks, facilitating high-integrity wire connections for 22-26 AWG solid copper conductors. Housed in a 1U reinforced SPCC steel chassis, the unit is engineered for structural durability and organized routing within server rooms and telecommunications closets. The front interface incorporates standardized RJ45 ports with gold-plated contacts to ensure low-resistance signaling, while the integrated cable management bar at the rear provides localized strain relief for incoming horizontal cabling runs.

Technical Specifications

* Model: 327316

* Part Number: 133461

* EAN: 4015867225981

* Port Count: 16-Port RJ45

* Category: Cat.6 U/UTP

* Form Factor: 1U 19" Rackmount

* Termination Type: 180° LSA (Krone) Blocks

* Wire Gauge Support: 22 - 26 AWG

* Contact Plating: 8µ" Gold over Nickel

* Chassis Material: SPCC Steel (Cold-rolled)

* Performance: 250 MHz / 1 Gbps

* Standards: ISO/IEC 11801, EN 50173, ANSI/TIA-568-C.2

* Features: Numbered ports, color-coded T568A/B wiring

Key Features

* High-Density Cat.6 Signal Architecture: Features a specialized internal PCB engineered to minimize Near-End Crosstalk (NEXT) and Return Loss, ensuring high-integrity 1000Base-T performance for mission-critical network uplinks.

* Professional-Grade LSA Termination Suite: Equipped with localized color-coded punch-down blocks designed for precision wire alignment according to T568A and T568B standards, reducing installation latency and failure rates.

* Reinforced Steel Chassis Engineering: Manufactured with a 1U cold-rolled steel housing designed to resist mechanical deformation and provide a stable grounding platform for networking hardware within standard 19-inch racks.

* Integrated Rear Cable Management Infrastructure: Incorporates a specialized support bar and cable ties designed to distribute mechanical tension away from individual termination points, maintaining long-term signal fidelity.

* Precision Gold-Plated Interface Design: Utilizes high-purity gold plating on the RJ45 contact pins to provide a low-resistance electrical bond and prevent oxidation in industrial or server room environments with varying humidity.
