Intel Core i7-14700 Processor, 33MB Smart Cache Tray
Reference:
1726215
EAN:
8592978516932
Condition:
New
Price:
€392.08
VAT included
Without tax:
€324.03
The Intel Core i7-14700 Processor features 20 cores and 28 threads with a base power of 65W and turbo frequency up to 5.4 GHz. Equipped with 33MB Smart Cache and Intel UHD Graphics 770, it supports DDR4 and DDR5 memory up to 192 GB. Ideal for workstations and PCs, it offers advanced technologies like Intel Hyper-Threading, Turbo Boost Max 3.0, and virtualization support, ensuring powerful and efficient performance.
Special features of the processor
Intel Hyper-Threading
Yeah
Intel® Clear Video HD Technology (Intel® CVT HD)
Yeah
Intel® Turbo Boost Max Technology 3.0
Yeah
Intel® 64
Yeah
Intel® Boot Guard
Yeah
Intel Enhanced SpeedStep Technology
Yeah
Intel® Thread Director
Yeah
Intel® Standard Management (ISM)
Yeah
Intel® Deep Learning Boost (Intel® DL Boost) on the CPU
Yeah
Intel® AES New Instructions (Intel® AES-NI)
Yeah
Intel® Speed Shift Technology
Yeah
Intel® Gaussian Neural Accelerator (Intel® GNA) 3.0
Yeah
Intel® Controlled Flow Application Technology (CET)
Yeah
Intel® Virtualization Technology for Directed I/O (VT-d)
Yeah
Intel® Turbo Boost Technology
2.0
Intel® Virtualization Technology (VT-x)
Yeah
Intel® OS Guard
Yeah
Intel® Quick Sync Video Technology
Yeah
Intel® Turbo Boost Technology Max Frequency 3.0
5.4 GHz
Intel® Secure Key
Yeah
Mode-based execution control (MBE)
Yeah
Intel® VT-x with Extended Page Tables (EPT)
Yeah
Intel® Volume Management Device (VMD)
Yeah
Graphics
DirectX version of the embedded graphics adapter
12.0
Compatible outputs of integrated graphics adapter
Integrated DisplayPort (eDP) 1.4b, HDMI 2.1, DisplayPort 1.4a
Maximum resolution of integrated graphics adapter (eDP - Integrated Flat Panel)
5120 x 3200 pixels
Number of supported screens (embedded graphics)
4
Number of execution units
32
Codec engines in multiple formats
2
Built-in graphics adapter
Yeah
Refresh rate of the integrated graphics adapter at maximum resolution (HDMI)
60 Hz
Maximum resolution of the built-in graphics adapter (HDMI)
4096 x 2160 pixels
Built-in graphics adapter model
Intel UHD Graphics 770
OpenGL version of the embedded graphics adapter
4.5
Discrete Graphics Adapter Model
Not available
Refresh rate of the integrated graphics adapter at maximum resolution (eDP - Integrated Flat Panel)
120 Hz
Dynamic frequency (max) of the embedded graphics adapter
1600 MHz
Integrated graphics adapter ID
0xA780
Maximum resolution of the integrated graphics adapter (DisplayPort)
7680 x 4320 pixels
Refresh rate of the integrated graphics adapter at maximum resolution (DisplayPort)
60 Hz
Built-in graphics base frequency
300 MHz
Discrete graphics adapter
Yeah
Characteristics
Market segment
Divest
Scalability
1S
Terms of use
Workstation, PC/Client/Tablet
Execution disable bit
Yeah
Available integrated options
Yeah
CPU configuration (maximum)
1
Intel Thermal Monitoring Technology
Yeah
PCI Express input version
5.0, 4.0
Supported instruction set
AVX 2.0, SSE4.1, SSE4.2
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1
Maximum number of PCI Express buses
20
DMI (Direct Media Interface) Review
4.0
PCI Express Configurations
2x8+1x4, 1x16+1x4
Inactivity states
Yeah
Memory
Channels of memory
Dual channel
ECC
Yeah
Types of memory supported by the processor
DDR5-SDRAM, DDR4-SDRAM
Maximum internal memory supported by the processor
192 GB
Memory bandwidth (max)
89.6 GB/s
Technical details
State
Launched
OpenCL version
3.0
Release date
Q1'24
Processor
Maximum turbo power
219 O
Staggering
B0
Processor manufacturer
Intel
Processor generation
Intel Core i7-14xxx
Maximum number of DMI lanes
8
Number of execution threads
28
Performance cores
8
Efficient core acceleration frequency
4.2 GHz
Processor model
i7-14700
Processor family
Intel® Core™ i7
Base processor power
65 W
ARK ID Processor
236781
Performance core throttle frequency
5.3 GHz
Processor codename
Raptor Lake
Efficiency cores
12
Operating processor mode
64 bits
Memory bandwidth supported by the processor (max)
89.6 GB/s
Processor cache type
Smart cache
Processor cache
33 MB
efficient core base frequency
1.5 GHz
Packaging type
Tray
Number of processor cores
20
performance core base frequency
2.1 GHz
Turbo processor frequency
5.4 GHz
Processor socket
LGA 1700
Logistics data
Harmonization System (HS) Code
8542310001
Other features
L2 cache
28672 KB
Maximum internal memory
192 GB
graphic production
eDP 1.4b, DP 1.4a, HDMI 2.1
Weight and dimensions
CPU size
45 x 37.5 mm
Environmental conditions
T Intersection
100 °C
-
