Intel Core Ultra 5 250k Plus Processor 30 MB Smart Cache Tray

INTEL CORE ULTRA 5 250K PLUS TRAY PROCESSOR (30M CACHE UP TO 5.30 GHZ) FCLGA18W AT807683B9B4886 99DAGP

Specs:

- Performance cores: 6
- Efficient cores: 12
- Performance-core boost frequency: 5.3 GHz
- Performance-core base frequency: 4.2 GHz
- Efficient-core boost frequency: 4.6 GHz
- Efficient-core base frequency: 3.3 GHz
- Processor base power: 125 W
- Maximum turbo power: 159 W
- Maximum number of DMI lanes: 8
- Processor generation: Intel Core Ultra (Series 2)
- CPU-compatible AI software development environments: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
- Low Power Efficient-cores: 0
- Processor manufacturer: Intel
- Processor family: Intel Core Ultra 5
- Number of processor cores: 18
- Processor socket: FCLGA1851
- Processor model: 250K Plus
- Number of processor filaments: 18
- Operating processor mode: 64 bits
- Processor cache: 30 MB
- Turbo processor frequency: 5.3 GHz
- Processor codename: Arrow Lake
- ARK Processor ID: 245694
- Processor cache type: Smart Cache
- Memory channels: Dual channel
- Maximum internal memory supported by the processor: 256 GB
- Memory types supported by the processor: DDR5-SDRAM
- ECC: Yes
- CPU size: 45 x 37.5 mm
- Maximum temperature: 105 °C
- OpenCL Version: 3.0
- Release date: Q1´26
- Status: Launched
- Graphic production: eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
- L2 cache: 30720 KB
- Maximum internal memory: 256 GB
- Xe cores: 4
- Compatible hardware codecs (encoding/decoding): H.264, H.265 (HEVC)
- GPU-compatible AI software development environments: DirectML, OpenVINO, Windows ML, ONNX RT, WebGPU
- AV1 Encoding/Decoding: Yes
- Integrated graphics adapter: Yes
- Discrete graphics adapter: No
- Graphics Card: Intel Graphics
- Discrete graphics adapter model: Not available
- Built-in graphics base frequency: 300 MHz
- Dynamic frequency (max) of integrated graphics adapter: 1900 MHz
- Number of supported screens (integrated graphics): 4
- Integrated graphics adapter DirectX version: 12.0
- Embedded graphics adapter OpenGL version: 4.5
- Maximum resolution of integrated graphics adapter (DisplayPort): 7680 x 4320 Pixels
- Onboard graphics adapter refresh rate at maximum resolution (DisplayPort): 60 Hz
- Integrated graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
- Built-in graphics adapter refresh rate at maximum resolution (HDMI): 60 Hz
- Integrated graphics adapter ID: 0x7D67
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Thread Director: Yes
- Intel® Threat Detection Technology (TDT): Yes
- Intel® Thunderbolt 4: Yes
- Intel® Standard Management (ISM): If
- Intel® Stable Image Platform Program (SIPP): Yes
- Intel® Virtualization Technology with Redirect Protection (VT-rp): Yes
- Intel® One-Click Recovery: Yes
- Intel® Remote Platform Erase (RPE): Yes
- Intel vPro® Enterprise platform eligibility: Yes
- Intel® Total Memory Encryption - Multikey: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on GPU: Yes
- Intel® Active Management Technology (Intel® AMT): Yes
- Intel Hyper-Threading: No
- Intel® Turbo Boost Technology: 2.0
- Intel® AES New Instructions (Intel® AES-NI): If
- Intel Enhanced SpeedStep Technology: Yes
- Intel® Trusted Execution Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® OS Guard: Yes
- Intel® 64: Yes
- Intel® Virtualization Technology (VT-x): Yes
- Intel® Virtualization Technology for Directed I/O (VT-d): If
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost): Yes
- Intel® Volume Management Device (VMD): Yes
- Suitability for the Intel® vPro™ platform: Yes
- Mode-based execution control (MBE): If
- Intel® Quick Sync Video Technology: Yes
- Use conditions: Workstation, PC/Client/Tablet
- DMI (Direct Media Interface) Revision: 4.0
- Execute Disable Bit: Yes
- Inactivity states: If
- Intel Thermal Monitoring Technology: Yes
- Maximum number of PCI Express buses: 24
- PCI Express slot version: 4.0, 5.0
- Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
- Scalability: 1S
- Integrated options available: No
- Market segment: Desktop
- Technical characteristics of the thermal solution: PCG 2020A
- Packaging type: Tray
- Neural Processing Unit (NPU): Intel AI Boost
- NPU core performance up to: 13 TOPs
- Dispersion support: Yes
- Windows Studio effects support: Yes
- AI software development environments compatible with the NPU core: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
- Total processor performance up to: 30 TOPs
- GPU performance up to: 8 TOPs
