Intel Core Ultra 5 225 Processor 20 MB Smart Cache Tray

INTEL CORE ULTRA 5 PROCESSOR 225 (20M CACHE UP TO 4.90 GHZ) FCLGA18W TRAY AT8076806415 99CMTF

Specs:

- Performance cores: 6
- Efficient cores: 4
- Performance-core boost frequency: 4.9 GHz
- Performance-core base frequency: 3.3 GHz
- Efficient-core boost frequency: 4.4 GHz
- Efficient-core base frequency: 2.7 GHz
- Processor base power: 65 W
- Maximum turbo power: 121 W
- Maximum number of DMI lanes: 8
- Processor generation: Intel Core Ultra (Series 2)
- CPU-compatible AI software frameworks: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
- Processor manufacturer: Intel
- Processor family: Intel Core Ultra 5
- Number of processor cores: 10
- Processor socket: LGA 1851 (Socket V1)
- Processor model: 225
- Number of processor filaments: 10
- Operating processor mode: 64-bit
- Processor cache: 20 MB
- Processor turbo frequency: 4.9 GHz
- Processor codename: Arrow Lake
- ARK Processor ID: 241070
- Processor cache type: Smart Cache
- Memory channels: Dual channel
- Maximum internal memory supported by the processor: 192 GB
- Memory types supported by the processor: DDR5-SDRAM
- Memory clock speed supported by the processor: 6400 MHz
- Maximum temperature: 105 °C
- OpenCL version: 3.0
- Release date: Q1´25
- Status: Launched
- Graphic production: DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
- L2 cache: 22528 KB
- Maximum internal memory: 192 GB
- Xe cores: 2
- Built-in graphics adapter: Yes
- Discrete graphics adapter: No
- Graphics Card: Intel Graphics
- Discrete Graphics Adapter Model: Not Available
- Built-in graphics base frequency: 300 MHz
- Built-in graphics adapter dynamic frequency (max): 1800 MHz
- Number of displays supported (built-in graphics): 4
- Built-in graphics adapter DirectX version: 12.0
- Built-in graphics adapter OpenGL version: 4.5
- Built-in graphics adapter refresh rate at maximum resolution (DisplayPort): 60 Hz
- Built-in graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel): 60 Hz
- Built-in graphics adapter refresh rate at maximum resolution (HDMI): 60 Hz
- Built-in graphics adapter ID: 0x7D67
- Supported built-in graphics adapter outputs: HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Thread Director: Yes
- Intel® Thunderbolt 4: Yes
- Intel® Standard Management (ISM): Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on GPU: Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Intel Enhanced SpeedStep Technology: Yes
- Intel® Trusted Execution Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® OS Guard: Yes
- Intel® 64: Yes
- Intel® Virtualization Technology (VT-x): Yes
- Intel® Virtualization Technology for Directed I/O (VT-d): Yes
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost): Yes
- Intel® Volume Management Device (VMD): Yes
- Mode-based execution control (MBE): Yes
- Intel® Quick Sync Video Technology: Yes
- Use conditions: PC/Client/Tablet
- DMI (Direct Media Interface) Revision: 4.0
- Execute Disable Bit: Yes
- Idle states: Yes
- Intel Thermal Monitoring Technology: Yes
- Maximum number of PCI Express buses: 24
- PCI Express Entry Version: 4.0, 5.0
- Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
- Scalability: 1S
- Integrated options available: Yes
- Market segment: Desktop
- Packaging type: Tray
- Neural Processing Unit (NPU): Intel AI Boost
- NPU core performance up to: 13 TOPs
- Dispersion support: Yes
- Windows Studio Effects Support: Yes
- AI software frameworks supported by the NPU core: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
- Total processor performance up to: 23 TOPs
- GPU performance up to: 4 TOPs
