Intel Core i5-14400 Processor 20 MB Smart Cache

INTEL CORE I5 PROCESSOR 14400 (20M CACHE, UP TO 4.70 GHZ) FC-LGA16A, TRAYCM8071504821112 99CFF9

Specs:

- Performance cores: 6
- Efficient cores: 4
- Performance-core boost frequency: 4.7 GHz
- Performance-core base frequency: 2.5 GHz
- Efficient-core boost frequency: 3.5 GHz
- Efficient-core base frequency: 1.8 GHz
- Processor base power: 65 W
- Maximum turbo power: 148 W
- Maximum number of DMI lanes: 8
- Processor generation: Intel Core i5-14xxx
- Processor manufacturer: Intel
- Processor family: Intel® Core™ i5
- Number of processor cores: 10
- Processor socket: LGA 1700
- Box: No
- Processor model: i5-14400
- Number of processor filaments: 16
- Operating processor mode: 64-bit
- Processor cache: 20 MB
- Processor turbo frequency: 4.7 GHz
- Processor codename: Raptor Lake
- Memory bandwidth supported by the processor (max): 76.8 GB/s
- ARK Processor ID: 236788
- Processor cache type: Smart Cache
- Grading: B0
- Memory bandwidth (max): 76.8 GB/s
- Memory channels: Dual channel
- Maximum internal memory supported by the processor: 192 GB
- Memory types supported by the processor: DDR4-SDRAM, DDR5-SDRAM
- CPU size: 45 x 37.5 mm
- Intersection T: 100 °C
- OpenCL version: 3.0
- Release date: Q1´24
- Status: Launched
- Graphic production: eDP 1.4b, DP 1.4a, HDMI 2.1
- L2 cache: 9728 KB
- Maximum internal memory: 192 GB
- Codec engines in multiple formats: 1
- Built-in graphics adapter: Yes
- Discrete graphics adapter: No
- Graphics Card: Intel® Graphics
- Discrete Graphics Adapter Model: Not Available
- Built-in graphics adapter dynamic frequency (max): 1550 MHz
- Number of displays supported (built-in graphics): 4
- Built-in graphics adapter DirectX version: 12.0
- Built-in graphics adapter OpenGL version: 4.5
- Maximum resolution of built-in graphics adapter (DisplayPort): 7680 x 4320 pixels
- Maximum resolution of built-in graphics adapter (eDP - Integrated Flat Panel): 5120 x 3200 pixels
- Maximum resolution of built-in graphics adapter (HDMI): 4096 x 2160 pixels
- Built-in graphics adapter refresh rate at maximum resolution (DisplayPort): 60 Hz
- Built-in graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
- Built-in graphics adapter refresh rate at maximum resolution (HDMI): 60 Hz
- Built-in graphics adapter ID: 0x4682/0xA782
- Supported built-in graphics adapter outputs: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
- Number of execution units: 24
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Thread Director: Yes
- Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
- Intel® Standard Management (ISM): Yes
- Intel Hyper-Threading: Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Intel Enhanced SpeedStep Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® OS Guard: Yes
- Intel® 64: Yes
- Intel® Virtualization Technology (VT-x): Yes
- Intel® Virtualization Technology for Directed I/O (VT-d): Yes
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost): Yes
- Intel® Volume Management Device (VMD): Yes
- Mode-based execution control (MBE): Yes
- Intel® Quick Sync Video Technology: Yes
- Intel® Clear Video HD Technology (Intel® CVT HD): Yes
- Use conditions: PC/Client/Tablet
- DMI (Direct Media Interface) Revision: 4.0
- Export Control Classification Number (ECCN): 5A992C
- Commodity Classification Automated Tracking System (CCATS): 740.17B1
- Execute Disable Bit: Yes
- Idle states: Yes
- Intel Thermal Monitoring Technology: Yes
- Maximum number of PCI Express buses: 20
- PCI Express Entry Version: 4.0, 5.0
- PCI Express configurations: 1x16+1x4, 2x8+1x4
- Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
- Scalability: 1S
- CPU Configuration (Maximum): 1
- Integrated options available: Yes
- Harmonization System (HS) Code: 8542310001
- Market segment: Desktop
