Cooler Master MWE Gold 850 V3 Power Supply Unit 850 W 24-pin ATX ATX Black

COOLER MASTER MWE GOLD 850 V3 850W ATX 3.1 NON MODULAR POWER SUPPLY (MPE-8506-ACAG-BEU)

Specs:

- Number of EPS connectors: 2
- Motherboard power supply: 24-pin ATX
- Peripheral power connectors (4 pin) (Molex): 3
- Number of SATA power connectors: 6
- PCI Express power connectors (6 + 2 pin): 4
- Motherboard power cable length: 55 cm
- SATA power cable length: 400,550,700 mm
- EPS power connector (8-pin): Yes
- Wiring Type: Non-modular
- Peripheral power cable length (Molex): 400,550,700 mm
- ATX power connector (24 pins): Yes
- EPS power connector (4+4 pins): Yes
- Width: 140 mm
- Depth: 150 mm
- Height: 86 mm
- Weight: 1.8 kg
- Product color: Black
- Fan diameter: 12 cm
- Number of fans: 1 Fan(s)
- Fan location: Top
- Integrated on/off switch: Yes
- Cooling type: Active
- Total power: 850 W
- AC input voltage: 100 - 240 V
- Maximum output current (+3.3V): 20 A
- Maximum output current (+12V): 70.8 A
- Maximum output current (+5V): 20 A
- Maximum output current (-12V): 0.3 A
- Maximum output current (+5Vsb): 3 A
- Power protection functions: Over current, Over voltage, Over total voltage, Over voltage, Short circuit, Under voltage
- AC input frequency: 50 - 60 Hz
- Input current: 6 - 10 A
- Power factor correction (PFC): Active
- Combined power (3.3 V): 100 W
- Combined power (+12 V): 849.6 W
- Combined power (+5 V): 100 W
- Combined power (-12V): 3.6 W
- Combined power (+5 VSB): 15 W
- Waiting time: 16 ms
- Efficiency: 90%
- Power Good signal delay margin: 100 - 150 ms
- Operating temperature range: 0 - 40 °C
- Use with: PC
- Power supply unit (PSU) form factor: ATX
- 80 PLUS Certification: 80 PLUS Gold
- ATX version: 3.1
- Mean time between failures: 100,000 h
- Bearing technology: HDB
- Cardboard box dimensions (Width x Depth x Height): 275 x 215 x 570 mm
- Package weight: 2.21 kg
- Package width: 190 mm
- Package depth: 110 mm
- Package height: 260 mm
- Packaging type: Box
- Sustainability certificates: ErP
- Compliance certificates: BIS, BSMI, CCC, CE, EAC, US Federal Communications Commission (FCC), RCM, TÜV mark, UKCA, cTUVus
