Fsp Hydro Ptm Pro 1650w Atx3.0(12v-2x6) Power Supply Unit 20+4 Pin Atx Atx Black

$270.85
without tax $270.85
PPA16F0101
4713224529054
New product
New ATX power supply specifications Updated ATX 3.0 specifications to meet the power demands of next-generation hardware and ensure users the most stable and cost-optimized performance possible with maximum power efficiency. High compatibility for high power The series features a native PCIe Gen 5 connector with support for 3 PCIe 6 slots and two graphics card pins, plus 2 CPU header slots for increased performance. Application of conformal protective coatings Anti-humidity, anti-dust and anti-stain Conformal coating protects the power supply and its internal components from dust, moisture and stains. The Hydro PTM PRO series is covered with a protective conformal coating to ensure reliable performance under extreme conditions and is proven to operate perfectly even at 95% relative humidity. LLC full-bridge topology with DC-DC module design The Hydro PTM PRO Series features extremely tight voltage regulation to ensure output voltage regulation is less than +/-1% over 10% load change, giving you superior efficiency and voltage stability. Fully modular design for quick and easy installation The fully modular design simplifies installation and allows you to use only the cables you need for a much neater, cleaner build. ECO switch, quieter fan and much more durable With the ECO button on, the power supply runs quietly with lower power consumption. The power supply fan will not operate when the power supply load is less than 30% for silent state. The Hydro PTM PRO series features a fan with FDB technology and an intelligent 0 dBA function to reduce noise. It also offers a much longer lifespan. 80 Plus® Platinum Certification The Hydro PTM PRO series is 80 Plus Platinum certified, meaning that its power supplies consume less heat and have a lower operating cost. The power supplies are guaranteed to operate at a minimum efficiency of 92% at a load of 50% of the power supply´s rated power. Compliance with IEC 62368 standard At FSP Group we have the most advanced green p Read more...

  •   Up to 3 years warranty
  •   100% secure payment
  •   14 days return
Whatsapp Share with your friends

Buy it now and receive it between Fri 5 and Thu 11 with GLS o Correos Express España $18.97

FSP HPT2-1650M ATX3.0 PSU-80 PLUS PLATINUM POWER SUPPLY, FULLY MODULAR

Specs:

- Motherboard power supply: 20+4 pin ATX
- Peripheral power connectors (4 pin) (Molex): 4
- Number of SATA power connectors: 12
- PCI Express power connectors (6 + 2 pin): 4
- CPU power connector (4+4 pin): Yes
- Wiring type: Fully modular
- Width: 150 mm
- Depth: 180 mm
- Height: 86 mm
- Fan on/off switch: Yes
- Product colour: Black
- Fan diameter: 13.5 cm
- Number of fans: 1 Fan(s)
- Integrated on/off switch: Yes
- Cooling type: Semi-passive
- Number of 12V rails: 1
- Total power: 1650 W
- AC input voltage: 110 - 240 V
- Maximum output current (+3.3V): 20 A
- Maximum output current (+12V): 137.5 A
- Maximum output current (+5V): 20 A
- Maximum output current (-12V): 0.3 A
- Maximum output current (+5Vsb): 3 A
- Power protection functions: Over current, Over voltage, Over voltage, Short circuit, Under voltage
- AC input frequency: 50 - 60 Hz
- Power factor correction type (PFC): Active
- Combined power (3.3V): 120W
- Combined power (+12 V): 1650 W
- Combined power (+5V): 120W
- Combined power (-12V): 3.6 W
- Combined power (+5 VSB): 15 W
- Efficiency: 94%
- Use with: PC
- Power Supply (PSU) Form Factor: ATX
- 80 PLUS Certification: 80 PLUS Platinum
- ATX version: 3.0
- Bearing technology: FDB
- EPS version: 2.92
