DeepCool PF700 power supply unit 700 W 20+4 pin ATX ATX Black

Description

DeepCool PF700 Power Supply Unit 700W 20+4 Pin ATX Black

DeepCool PF700, 700 W, 220 - 240 V, 50 Hz, 100 W, 696 W, 100 W

Key product points

700 W 220 - 240 V 50 Hz

Motherboard power supply: 20+4 pin ATX

ATX 80 PLUS PC/Server

Active 12 cm

Black

Power control

Total power: 700 W

AC input voltage: 220 - 240 V

AC input frequency: 50 Hz

Combined power (3.3V): 100W

Combined power (+12 V): 696 W

Combined power (+5 V): 100 W

Combined power (-12V): 3.6 W

Combined power (+5 VSB): 12.5 W

Maximum output current (+3.3V): 15 A

Maximum output current (+12V): 58 A

Maximum output current (+5V): 15 A

Maximum output current (-12V): 0.3 A

Maximum output current (+5Vsb): 2.5 A

Waiting time: 12 ms

Efficiency: 85%

Power protection functions: Overvoltage, Overvoltage, Short circuit, Undervoltage

Ports and Interfaces

Motherboard power supply: 20+4 pin ATX

Motherboard power cable length: 55 cm

Number of SATA power connectors: 4

SATA power cable length: 450,600,750,900 mm

EPS power connector (4+4 pins): Yes

PCI Express Power Connectors (6+2 pin): 2

Wiring Type: Non-modular

Performance

80 PLUS Certification: 80 PLUS

Use with: PC/Server

Power supply unit (PSU) form factor: ATX

ATX version: 2.4

Mean time between failures: 100,000 h

Design

Product color: Black

Cooling Type: Active

Fan diameter: 12 cm

Number of fans: 1 Fan(s)

Integrated on/off switch: Yes

Environmental conditions

Operating temperature range: 0 - 40°C

Package contents

Cables included: AC

Weight and dimensions

Width: 150 mm

Depth: 140 mm

Height: 86 mm

Packaging

Packaging Type: Box
