Mobile POS Module/unattended F310-2 Feitian

Pogopin 8-pin connection to main F310: Secure magnetic coupling for charging, data and full control, turning the handheld into a fixed kiosk without transaction interruptions.

Industrial RS232/RS485 and 100 Mbps LAN interfaces: RJ45 ports for wired peripherals, external printers or stable networks in remote deployments.

MDB Multi-Drop Bus (Master/Slave) support: Standard protocol for coin/ticket validators, dispensers and vending machines, handling mixed payments without extra software.

Programmable digital I/O (PWR/DIG): Relays for lights, sensors, locks or displays, automating flows such as post-payment activation or error alerts.

Optional integrated thermal printer (58 mm): Speed 70-80 mm/s with auto cutter, offline buffer for tickets during disconnections, perfect for QR receipts or promotions.

Secondary 2.4-3.5 inch client display: Touch IPS (optional) for dual confirmations, self-service menus or dynamic advertising in unattended mode.

Rugged 5-12V DC/2-3A power supply: PoE support via LAN or universal adapter, with surge protection for continuous outdoor operation.

Rugged IP66 construction (440-530 g total): Dimensions ~232x95x97 mm, drops 1.8 m, -10°C to 50°C, ideal for vending exposed to dust/moisture.

1.5-3W audio and legacy vibration: Speaker/mic for audible alerts, haptic confirmations in noisy environments such as stations or supermarkets.

Scalable expansion: Combine with F310QCMRS for full NFC/IC/MSR, or UHF RFID/fingerprint modules for secure unattended access.

Remote management via Android 13 of the F310: OTA updates, centralised logs and fleet monitoring for minimal maintenance.

Legacy PCI 6.x/EMV security: Full encryption on all interfaces, tamper-proof physical connections for global compliance.
