14-in-1 Thunderbolt 4 Docking Station | DUF-E01
Connect storage, peripherals, networks, and displays with 14 ports, optimizing tasks and maximizing productivity.
Enjoy fast 40Gbps data transfer, triple 4K displays or single 8K displays, and 60W power delivery through a single connection. Backward compatible with previous USB versions.
Transfer large files, 8K videos, and backups in seconds with Thunderbolt 4's fast 40Gbps bandwidth, along with three 10Gbps USB ports and one 5Gbps port.
With a Thunderbolt 4 connection, your laptop receives 60W of fast charging, plus an additional 15W for phones, tablets, or accessories, powering all your devices together with ease.
Designed with aluminum alloy and thermal ventilation for efficient cooling, with a magnetic stand that enhances both style and order in the workspace.
Connectivity and ports
Video ports:
1 x HDMI 2.1 with resolution up to 7680 x 4320 at 30 Hz
1 x DisplayPort 1.4 with resolution up to 7680 x 4320 at 30 Hz
1 x Thunderbolt 4 Multifunction
Network port: 1 x RJ45 10/100/1000 Mbps
USB and Thunderbolt ports:
1 x Thunderbolt 4 with speeds up to 40 Gbps and 15 W output
1 x USB 3.1 Type-C with speeds up to 10 Gbps
2 x USB 3.1 Type-A ports with speeds up to 10 Gbps
1 x USB 3.0 Type A with speeds up to 5 Gbps
2 x USB 2.0 Type A ports with speeds up to 480 Mbps
Card reader: SD and microSD slots compatible with UHS-II and capacities from 32 GB to 2 TB
Audio: 3.5 mm combined jack connector for audio and microphone
Host connector: Thunderbolt 4 with up to 40 Gbps and Power Delivery 3.0 up to 60 W
Video resolution
HDMI 2.1: Up to 8K at 30Hz on one monitor or up to 4K at 60Hz on two or three screen setups
DisplayPort 1.4: Up to 8K at 30Hz on a single monitor or up to 4K at 60Hz on two or three display setups
Thunderbolt 4: Up to 8K at 30Hz on one monitor or up to 4K at 60Hz on two or three screen setups
Compatible systems
Operating systems: macOS, Windows 10, Windows 11 and Android
Design and dimensions
Dimensions: 188 x 40 x 125 mm
Weight: 1.2 kg
Feeding
Maximum power consumption: 135 W with 24 V and 5.63 A adapter
Operating conditions
Operating temperature: 0 to 40 °C
Storage temperature: -20 to 65 °C
Operating humidity: 10% to 90% non-condensing
Storage humidity: 5% to 95% non-condensing
Certifications
Certifications: FCC and CE
Package contents
Docking station: DUF-E01 Thunderbolt 4 14 in 1
Cable: 50cm Thunderbolt 4
Power adapter: Included
Documentation: Quick installation guide and warranty card
