Axis 01512-001 3/4" Conduit Locknut A Pack 4 pcs T91B53 Telescopic Ceiling Mount Pendant Kit Accessory

Axis M3057-PLVE Mk II Network Camera - White (7331021064331)

The Axis 01512-001 (M3057-PLVE Mk II) is a professional-grade 6-megapixel panoramic network camera designed for high-integrity 360° or 180° situational awareness. This hardware features an IK10-rated vandal-resistant and IP66/67-rated weather-resistant enclosure, making it suitable for demanding indoor and outdoor deployments. It utilizes a high-performance 1/1.8-inch sensor to deliver detailed fisheye views and multiple dewarped viewing modes, including panorama, quad, and corner views. Engineered for low-light excellence, the camera incorporates Axis Lightfinder and Forensic WDR technologies, alongside integrated 360° IR illumination with individually controllable LEDs to eliminate shadows in total darkness. The device includes Axis Zipstream technology with support for H.264 and H.265 video compression, significantly reducing bandwidth and storage requirements while preserving critical forensic details.

Technical Specifications

* Model: M3057-PLVE Mk II

* Part Number: 01512-001

* Image Sensor: 1/1.8" Progressive Scan RGB CMOS

* Resolution: 6 MP (2048 x 2048 for Fisheye)

* Lens: 1.2 mm, F2.2, Fixed Iris

* Field of View: 180° Horizontal / 180° Vertical (360° Overview)

* Day/Night: Automatically removable infrared-cut filter

* Minimum Illumination: Color: 0.16 lux; B/W: 0.03 lux (0 lux with IR)

* IR Illumination: 360° OptimizedIR (up to 20 m range)

* Video Compression: H.264 (MPEG-4 Part 10/AVC), H.265 (MPEG-4 Part 11/HEVC), Motion JPEG

* Audio: Built-in microphone; supports two-way audio via port-cast

* Storage: microSD/microSDHC/microSDXC slot (supports up to 256 GB)

* Power: Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3

* Dimensions: ø 149 x 66 mm

Key Features

* 360° Complete Situational Awareness: Utilizes a high-precision fisheye lens to capture a total hemispherical field of view, eliminating blind spots within a single hardware deployment.

* Integrated 360° OptimizedIR: Features an intelligent infrared system that automatically adapts to the camera's zoom level and field of view, providing uniform illumination in zero-light environments up to 20 meters.

* Industrial Environmental Hardening: Encased in a robust housing certified with IP66, IP67, and NEMA 4X ratings for weather protection, and IK10 for high-impact mechanical resistance.

* Advanced Forensic Imaging: Employs Forensic WDR to handle complex lighting scenarios with both dark and bright areas, and Lightfinder technology for high-color saturation in near-nocturnal conditions.

* Edge-Based AI Processing: Built on the ARTPEC-7 chipset, enabling sophisticated on-device analytics such as motion detection, tampering alarms, and support for third-party applications via the AXIS Camera Application Platform.
