ALLNET Switch Modul ALL4764 SFP+(Mini-GBIC), 10Gbit, B(Bidi)B/LC, Tx1330nm/Rx1270nm, 9u, 20Km,

The ALLNET ALL4764 is a high-performance SFP+ transceiver module designed for 10 Gigabit Ethernet networks. It operates on a single LC fiber using BiDi (Bidirectional) technology, transmitting at 1330nm and receiving at 1270nm. This module supports distances up to 20km over single-mode fiber (9µm core), making it ideal for long-reach connections in enterprise and data center environments.

Compliant with SFF-8431 and SFF-8472 standards, the ALL4764 features digital diagnostics monitoring (DDM) for real-time performance tracking. It is hot-pluggable, low power (typically <1W), and supports a wide operating temperature range. The module is fully compatible with ALLNET switches and other MSA-compliant SFP+ equipment.
