Switch Level One No Management 24P Giga Metallic

Gigabit speeds - take your data to the next level

GEU-2431 is a 24-port Gigabit Ethernet switch that gives you a seamless, high-performance, low-cost, and easy-to-use upgrade to boost your network to 1000 Mbps. Boost your network backbone speed to a massive 48GBps and bring ultra-fast Gigabit connections to all your computers.

Hungry for bandwidth? It is not a problem.

What happens when you have several users accessing multimedia applications at the same time? Don't worry, the GEU-2431 allows you to move large files faster and easier. Transfer your CGI, CAD, video or other large media files over the network instantly and without delay.

Plug and play, flexible and easy

GEU-2431 is plug-and-play, so no configuration is required. Automatic detection of MDI/MDI-X cables on all ports eliminates the need for crossover cables or Uplink ports. Each port can be used as a general port or uplink port, and any port can be simply connected to a server, hub, router, or switch, using a straight-through or crossover cable.

Approval and complianceCE RoHS
Operating Humidity 5 RH ~ 90 RH
Operating temperature -10°C ~ 55°C
Storage Humidity 5 RH ~ 95 RH
Storage temperature -40°C ~ 75°C
Backplane (Gbps)48 Gb/s
Packet buffer40.32Mpps
Dip switch NOM (standard normal), VLAN (Isolation from port 1-22 uplink from port 23-24), CENK (flow control mode)
IndicatorsPower Link/Activity/Speed
Jumbo Frame (KB)9 KB
MAC8K address table
RAM Size4.1MB
Mount 19? rack mount, desk mount
Power supply 100-240 V AC, 50-60 Hz, 1 A
StandardsIEEE 802.3 10-BASE-T, Ethernet IEEE 802.3u 100-BASE-TX, FTXt Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE802.3x Flow and backpressure control
Product weight (kg)1.6
ColorBlack
EAN4015867228142
Model numberGEU-2431
Package ContentsGEU-2431 Power Cable
- 19? rack mounting kit Quick installation guide Declaration of conformity
Commercial Qualification
Data rate Gigabit Ethernet
PoENo-compliant
ManageableNo
no fan yes
Simultaneous Ports24.00 Ports
Power consumption25W
