TP-Link TL-SF1024D Switch 24 Ports

TheTL-SF1024D°Fast Ethernet Switch offers high performance, low cost, ease of use, seamless upgrades, and is a standard for upgrading older 100Mbps networks. With 24 auto MDI/MDIX ports, there's no need to worry about cable typesimply plug and play. Furthermore, thanks to innovative energy-efficient technology, theTL-SF1024D?can save up to 75% onower consumption, and 80% of its packaging material is recyclable, making it an environmentally friendly solution for your business network.

Characteristics

• High performance.The metal rack-mount design of the enclosure, along with a certified internal power supply, makes this a robust and cost-effective switch for environments with fewer than 24 users. Featuring a non-blocking switching architecture, the TL-SF1024D forwards and filters packets at wire speed for maximum throughput. IEEE 802.3x flow control for full-duplex mode and backpressure for half-duplex mode alleviate traffic congestion and ensure reliable operation.
• TP-Link Green Technology.This new generation TL-SF1024D Fast Ethernet Switch offers the latest in energy efficiency with innovative technologies that can expand your network capacity using significantly less power. It automatically adjusts power consumption according to link status and cable length to limit your network's carbon footprint. It is also compliant with EU RoHS regulations, which prohibit the use of certain hazardous materials. Furthermore, 70% of the packaging material is recyclable.
• Easy to Use.This auto Fast Ethernet switch features a plug-and-play installation that's hassle-free. No configuration is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port detects the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

TP-Link TL-SF1024D Specifications

• Management features
  • Switch Type: Unmanaged

• Ports and Interfaces
  • Number of basic RJ-45 Ethernet switching ports: 24

• Connection
  • Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
  • Full duplex: Yes
  • Flow control support: Yes
  • Auto MDI / MDI-X: Yes

• Data transmission
  • Supported transfer rates: 10/100 Mbps
  • Switching capacity: 4.8 Gbit/s
  • MAC address table: 8000 entries
  • Save and forward: If
  • Transfer rate (max): 0.1 Gbit/s

• Security
  • MAC, address filter: If

• Protocols
  • Supported network protocols: CSMA/CD, TCP/IP

• Design
  • Rack mount: Yes
  • LED Indicators: Link, Power
  • Certification: FCC, CE

• Environmental conditions
  • Operating temperature range: 0 - 40°C
  • Storage temperature range: -40 - 70 °C
  • Relative humidity range for operation: 10 - 90%
  • Relative humidity range during storage: 5 - 90%

• Other features
  • Dimensions (Width x Depth x Height): 294 x 180 x 44 mm
  • Connectivity technology: Wired
  • Power requirements: 100 - 240VAC, 50/60Hz
  • Wifi: No
