GIGABYTE Z890 AORUS
Specs:
- Processor manufacturer: Intel
- Processor socket: LGA 1851 (Socket V1)
- Supported processor: Intel Core Ultra (Series 2)
- Supported processor sockets: LGA 1851
- Maximum internal memory supported by the processor: 256 GB
- Maximum supported memory clock speed: 9500 MHz
- ECC compatibility: ECC and non-ECC
- Maximum internal memory per slot: 64 GB
- supported memory types: DDR5-SDRAM
- Number of memory slots: 4
- Memory slot type: DIMM
- Maximum internal memory: 256 GB
- Memory channels: Dual channel
- Supported memory clock speeds: 5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8200,8266,8400,8600,9500 MHz
- Unbuffered memory: Yes
- Wi-Fi standard: Wi-Fi 7 (802.11be)
- WLAN Controller Model: Intel Wi-Fi 7 BE200
- Ethernet: Yes
- Ethernet interface type: 10 Gigabit Ethernet
- LAN Controller: Marvell AQtion AQC113C
- Wifi: Yes
- Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
- Bluetooth: Yes
- Bluetooth version: 5.4
- USB 3.2 Gen 2x2 connectors: 2
- Number of CPU fan connectors: 2
- Number of water pump connectors: 2
- Number of RGB LED pin headers: 4
- Number of EPS power connectors (8-pin): 2
- Number of temperature sensor headers: 2
- Number of noise detection headers: 1
- USB 2.0, connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of SATA III connectors: 4
- ATX power connector (24 pin): Yes
- CPU fan connector: Yes
- Number of chassis fan connectors: 3
- Front panel connector: Yes
- EPS power connector (8-pin): Yes
- Connector for RGB LED strips: Yes
- Thunderbolt headers: 1
- USB 2.0: 0
- USB 3.2 Gen 1 (3.1 Gen 1): 0
- Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports: 10
- Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports: 0
- USB 3.2 Gen 1 (3.1 Gen 1) Type C: 0
- Ethernet LAN ports (RJ-45): 2
- S/PDIF output port: Yes
- WiFi-AP antenna connector: 2
- VGA (D-Sub) ports: 0
- HDMI ports: 0
- Number of DVI-D ports: 0
- Headphone jack: 1
- Microphone input: Yes
- Number of Thunderbolt ports: 2
- RAID Support: Yes
- Number of supported storage units: 8
- Supported storage disk interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID levels: 0, 1, 5, 10
- Number of HDDs supported: 4
- PCI Express x16 (Gen 5.x) slots: 2
- 1st M.2 largest key size: 25110
- 1st M.2 highest PCI Express generation: 5.0
- 2nd M.2 largest key size: 25110
- 2nd M.2 highest PCI Express generation: 4.0
- 3rd M.2 largest key size: 22110
- 3rd M.2 highest PCI Express generation: 4.0
- 4th M.2 largest key size: 22110
- 4th M.2 highest PCI Express generation: 4.0
- PCI Express x16 (Gen 4.x) Slots: 1
- Number of M.2 (M) slots: 4
- BIOS types: UEFI AMI
- BIOS, memory size: 256 MB/s
- ACPI version: 5.0
- Clear CMOS Jumper: Yes
- System Management BIOS (SMBIOS) version: 2.7
- CMOS clear button: Yes
- Desktop Management Interface (DMI) version: 2.7
- Parallel processing support: Not supported
- Maximum resolution: 7680 x 4320 pixels
- HDCP: Yes
- DirectX version: 12.0
- Product colour: Black
- Chipset family: Intel
- Chipset: Intel Z890
- Form factor: Extended ATX
- Audio output channels: 2.0 channels
- Sound chip: ESS ES9280AC + ESS ES9080
- Component for: PC
- Supported Windows operating system: Windows 11 x64
- PC health monitoring: Fan, Temperature, Voltage, Water cooling
- Width: 304.8 mm
- Depth: 305 mm
- Package width: 386 mm
- Package depth: 370 mm
- Package height: 140 mm
- Weight: 5.03 kg
- Package weight: 6.7 kg
- Height: 35 mm
- Batteries included: Yes
- Screws included: Yes
- Antenna included: Yes
- Software included: Norton® Internet Security (OEM version)LAN bandwidth management software
- Warranty period: 3 year(s)
- Battery weight: 3 g
- Lithium weight per battery: 0.07 g
- Cells: 1
- Battery type: Lithium-Manganese Dioxide (LiMnO2)
- Battery type: CR2032
- Country of origin: Taiwan
- Quantity per shipping box: 1 piece(s)
