Gigabyte B760m Gaming Plus Wifi Ddr4 Motherboard - Supports 14th Gen Intel Core Processors, 4+1+1 Phase Vrm, Up To 5333Mhz Ddr4(

GIGABYTE B760M GP WIFI DDR4 BOARD, INTEL, 1700, B760, 4DDR4

Specs:

- Processor manufacturer: Intel
- Processor socket: LGA 1700
- Compatible processor: Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen , Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th G
- Supported processor sockets: LGA 1700
- Maximum internal memory supported by the processor: 128GB
- Maximum supported memory clock speed: 5333 MHz
- ECC compatibility: ECC and non-ECC
- Maximum internal memory per slot: 32GB
- supported memory types: DDR4-SDRAM
- Number of memory slots: 4
- Memory slot type: DIMM
- Maximum internal memory: 128GB
- Memory channels: Dual channel
- Supported memory clock speeds: 2133,2400,2666,2933,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866,4000,4133,4266,4300,4400,4500, 4600,4700,4800,4933,5000,5133,5333 MHz
- Unbuffered memory: Yes
- Wi-Fi Standard: Wi-Fi 6 (802.11ax)
- WLAN controller model: Realtek RTL8851BE
- Ethernet: Yes
- Ethernet interface type: Gigabit Ethernet
- LAN Controller: Realtek RTL8111H
- Wifi: Yes
- Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
- Bluetooth: Yes
- Bluetooth version: 5.3
- Number of CPU fan connectors: 1
- Number of RGB LED pin headers: 2
- Number of EPS power connectors (8-pin): 1
- USB 2.0, connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of SATA III connectors: 4
- Front panel audio connector: Yes
- ATX power connector (24 pin): Yes
- CPU fan connector: Yes
- Number of chassis fan connectors: 3
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
- Front panel connector: Yes
- EPS power connector (8-pin): Yes
- S/PDIF output connector: Yes
- Connector for RGB LED strips: Yes
- TPM connector: Yes
- Serial port header: 1
- Parallel connector: Yes
- Line input: Yes
- USB 2.0: 2
- USB 3.2 Gen 1 (3.1 Gen 1): 3
- Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports: 0
- Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports: 0
- USB 3.2 Gen 1 (3.1 Gen 1) Type C: 0
- PS/2 mouse port: 1
- Ethernet LAN ports (RJ-45): 1
- WiFi-AP antenna connector: 2
- VGA (D-Sub) ports: 0
- HDMI ports: 1
- Number of DVI-D ports: 0
- HDMI version: 2.1
- DisplayPort: 1
- DisplayPort version: 1.2
- Headphone jack: 1
- RAID Support: Yes
- Number of supported storage units: 6
- Supported storage disk interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID levels: 0, 1, 5, 10
- Number of HDDs supported: 4
- 1st M.2 largest key size: 2280
- 1st M.2 highest PCI Express generation: 4.0
- 2nd M.2 largest key size: 2280
- 2nd M.2 highest PCI Express generation: 4.0
- PCI Express x16 (Gen 4.x) Slots: 1
- Number of M.2 (M) slots: 2
- PCI Express x1 (Gen 3.x) slots: 2
- BIOS types: UEFI AMI
- BIOS, memory size: 128 MB/s
- ACPI version: 5.0
- Clear CMOS Jumper: Yes
- System Management BIOS (SMBIOS) version: 2.7
- Desktop Management Interface (DMI) version: 2.7
- Parallel processing support: Not supported
- Maximum resolution: 4096 x 2304 pixels
- HDCP: Yes
- DirectX version: 12.0
- Product colour: Grey
- Chipset family: Intel
- Chipset: B760
- Form factor: Micro ATX
- Audio output channels: 7.1 channels
- Sound chip: Realtek ALC897
- Power supply: ATX
- Component for: PC
- Supported Windows operating system: Windows 10 x64, Windows 11 x64
- PC health monitoring: Fan, Temperature, Voltage, Water cooling
- Width: 244 mm
- Depth: 244 mm
- Package width: 270 mm
- Package depth: 268 mm
- Package height: 68 mm
- Package weight: 1.2 kg
- Height: 35 mm
- Batteries included: Yes
- Screws included: Yes
- Antenna included: Yes
- Software included: Norton® Internet Security (OEM version)LAN bandwidth management software
- Warranty period: 3 year(s)
- Battery weight: 3 g
- Lithium weight per battery: 0.07 g
- Cells: 1
- Battery type: Lithium-Manganese Dioxide (LiMnO2)
- Battery type: CR2032
- Country of origin: China
- Quantity per shipping box: 1 piece(s)
