Gigabyte H610m H V3 Ddr4 Motherboard Intel H610 Express Lga 1700 Micro Atx

GIGABYTE H610M H V3 DDR4 BOARD,INTEL,1700,H610,2DDR4,64GB,VGA+HDMI,GBLAN,4SATA3+M.2,4USB3.2,MATX

Specifications:

- Processor manufacturer: Intel
- Processor socket: LGA 1700
- Compatible processor: Intel Celeron?, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium? Gold
- Supported processor sockets: LGA 1700
- Maximum memory clock speed supported: 3200 MHz
- supported memory types: DDR4-SDRAM
- Number of memory slots: 2
- Type of memory slots: DIMM
- Maximum internal memory: 64GB
- Memory channels: Dual channel
- Supported memory clock speeds: 3200, 3000, 2933, 2666, 2400, 2133 MHz
- ECC: Yes
- Non-ECC: Yes
- Unbuffered memory: Yes
- Supported memory module capacities: 1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB
- Ethernet: Yes
- Ethernet interface type: Gigabit Ethernet
- Wifi: No
- USB 2.0, connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of SATA III connectors: 4
- Audio connector on front panel: Yes
- ATX power connector (24 pins): Yes
- CPU fan connector: Yes
- Front panel connector: Yes
- EPS power connector (8-pin): Yes
- 12 V electrical connector: Yes
- Connector for RGB LED strips: Yes
- TPM Connector: Yes
- Serial port header: 1
- USB 2.0: 4
- USB 3.2 Gen 1 (3.1 Gen 1): 2
- PS/2 mouse port: 1
- Ethernet LAN ports (RJ-45): 1
- VGA ports (D-Sub): 1
- HDMI ports: 1
- Number of DVI-D ports: 1
- DisplayPort: 2
- Headphone jack: 3
- USB connector: USB type A
- Microphone Input: Yes
- Number of storage drives supported: 5
- Supported storage drive interfaces: M.2, SATA III
- Types of storage drives supported: HDD & SSD
- Number of HDDs supported: 1
- PCI Express x1 slots: 1
- PCI Express x16 slots: 1
- Number of M.2 slots (M): 1
- BIOS types: UEFI AMI
- BIOS, memory size: 128 MB/s
- ACPI Version: 5.0
- Jumper Clear CMOS: Yes
- System Management BIOS (SMBIOS) version: 2.7
- CMOS cleaning button: Yes
- Desktop Management Interface (DMI) Version: 2.7
- Support for parallel processing: Not supported
- Maximum resolution: 4096 x 2304 Pixels
- Graphics chipset: Intel
- Graphics adapter: HD Graphics
- HDCP: Yes
- Product color: Black
- Chipset family: Intel
- Chipset: Intel H610
- Form factor: Micro ATX
- Audio output channels: 7.1 channels
- Sound chip: Realtek ALC897
- Power: ATX
- Component for: PC
- Supported Windows operating system: Windows 10 x64, Windows 11 x64
- Cooling type: Active
- PC health monitoring: Fan, Temperature, Voltage, Water cooling
- Width: 230mm
- Depth: 215mm
- Package width: 265mm
- Package depth: 235mm
- Package height: 52mm
- Package weight: 684g
- Height: 35mm
- Batteries included: Yes
- Cables included: SATA
- Software included: Norton Internet Security (OEM version) LAN bandwidth management software
- Warranty period: 3 year(s)
- Battery weight: 3g
- Lithium weight per battery: 0.07 g
- Cells: 1
- Battery type: Lithium-Manganese Dioxide (LiMnO2)
- Battery type: CR2032
- Country of origin: China
- Quantity per shipping box: 1 piece(s)
