iiyama LH5075UHS-B1AG 125.7 cm (49.5") LCD Wifi 500 cd/m² 4K UHD Black Signage Display

Description

iiyama LH5075UHS-B1AG Digital Signage Display Flat Screen 125.7 cm (49.5") LCD Wifi 500 cd/m² 4K Ultra HD Black Built-in Android 11 Processor4/7

iiyama LH5075UHS-B1AG, Flat Panel Display for Digital Signage, 125.7 cm (49.5"), LCD, 3840 x 2160 Pixels, Wifi, 24/7

Exhibition

• Screen type: IPS
• Screen diagonal: 125.7 cm (49.5")
• Display technology: LCD
• Screen resolution: 3840 x 2160 pixels
• Screen brightness: 500 cd/m²
• HD Type: 4K Ultra HD
• Touchscreen: No
• Native aspect ratio: 16:9
• Response time: 9.5 ms
• Contrast ratio (typical): 5000:1
• Horizontal viewing angle: 178°
• Vertical viewing angle: 178°
• Number of screen colors: 1.07 trillion colors
• Pixel size: 0.285 x 0.285 mm
• Active display area (W x H): 1095.8 x 616.4 mm
• Screen diagonal: 125.7 cm
• Maximum frame rate: 60 fps
• Horizontal scan range: 28 - 160 kHz
• Fog index: 25%
• RGB color space: sRGB

Ports and Interfaces

• Number of HDMI ports: 3
• HDMI version: 2.0
• Number of DisplayPorts: 1
• DisplayPort version: 1.2
• USB port: Yes
• Number of USB ports: 2
• USB version: 2.0
• Ethernet: Yes
• Ethernet LAN (RJ-45) number of ports: 1
• Wi-Fi: Yes
• Wi-Fi standards: Wi-Fi 5 (802.11ac)
• PC audio input: Yes
• RS-232C: Yes
• Remote input (IR): 1
• Remote (IR) output: 1
• Integrated card reader: Yes
• Compatible memory cards: MicroSD (TransFlash)

Audio

• Built-in speakers: Yes
• Number of built-in speakers: 2
• RMS rated power: 20 W

Design

• Product design: Flat panel display for digital signage
• Supported placement: Interior
• Orientation: Horizontal/Vertical
• Product color: Black
• VESA mount: Yes
• Mounting panel interface: 400 x 400 mm
• Frame width (bottom): 1.49 cm
• Frame width (side): 1.49 cm
• Frame width (top): 1.49 cm

Performance

• Use with: Universal
• On-Screen Display (OSD): Yes
• Number of OSD languages: 15
• OSD Languages: Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Polish, Russian, Swedish
• Operating hours (hours/days): 24/7
• HDCP: Yes
• HDCP version: 2.2
• Mean time between failures: 44000 h

Energy control

• Energy consumption: 112 W
• Power consumption (idle): 0.5 W
• Power consumption (off): 0.3 W
• Energy efficiency class (SDR): G
• Energy consumption (SDR) per 1000 hours: 112 kWh
• AC input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz
• Energy efficiency scale: From A to G

Computer system

• Built-in processor: Yes
• Processor manufacturer: ARM
• Processor family: ARM Cortex
• Processor architecture: ARM Cortex-A53+Cortex-A73
• Number of processor cores: 4
• Internal memory: 4 GB
• Built-in graphics adapter model: ARM Mali-G52
• Internal storage capacity: 32 GB
• Installed operating system: Android 11

Weight and dimensions

• Screen width: 1122.7 mm
• Screen depth: 55 mm
• Screen height: 643.6 mm
• Screen weight: 11.8 kg

Packaging

• Package width: 1261 mm
• Package depth: 132 mm
• Package height: 761 mm
• Package weight: 16.2 kg

Package contents

• Remote control included: Yes
• Batteries included: Yes
• Cables included: AC power, HDMI, RS-232

Environmental conditions

• Operating temperature range: 0 - 40°C
• Storage temperature range: -20 - 60 °C

Regulatory approvals

• Certification: CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH

Technical details

• Certificates of conformity: RoHS

Other features

• Quick Setup Guide: If
• Case material: Metal
