ATTE ETH10-2wire Converter Set

The Atte ETH10-2wire-SET is a set of active converters designed for efficient multiswitch installations, enabling the distribution of satellite, terrestrial TV, and radio signals over a single fibre optic cable. It supports 2x TV-SAT and 1x TV/FM signals, making it a versatile choice for modern TV signal management.

This set features PoE IN and PoE OUT ports, each with overload protection at 0.6 A, ensuring safe and reliable power delivery. Surge protection is integrated on both LAN and DATA lines to safeguard connected equipment. The device consumes only 1.35 W across the entire track, making it energy efficient.

Designed for professional use, the ETH10-2wire-SET supports a 2WIRE track cable length of up to 1000 meters using two single twisted wires. LED indicators provide clear signaling for link status, data transmission, and power presence, simplifying installation and monitoring.

Its compact dimensions (51 x 51 x 22 mm) and IP20 protection rating make it suitable for various mounting options, including TH35 rails with additional latches. The device operates reliably within a temperature range of -25°C to +65°C, ensuring performance in diverse environments.

Ideal for satellite and terrestrial TV distribution, the Atte ETH10-2wire-SET offers a complete and professional solution for multiswitch installations with PoE capabilities and robust protection features.
