RJ45 to SC Gigabit Media Converter - Single-Mode Fiber - 1310nm - 20km

Main technical specifications

• Speed: Gigabit Ethernet (10/100/1000 Mbps) full-duplex auto-negotiation.

• Fibre type: Single-mode SMF 9/125 µm; wavelength 1310 nm (TX/RX).

• Maximum range: 20 km without repeaters; RJ45 → SC simplex connectors.

• Standards: IEEE 802.3ab/z/u (1000Base-TX/LX), compatible with Dahua SFP switches.

Design features

• Power: Dual input DC 12-48 V or passive PoE; power consumption <3 W.

• Dimensions: Compact DIN desktop (≈100×70×30 mm); rack/wall mounting optional.

• LED indicators: PWR, L/A (RJ45 link/activity), F/A (fibre), speeds.

• Temperature: -20°C to +70°C; IP40 metal housing with ESD protection.

Ecosystem compatibility

Perfect for extending your Dahua-Ruijie network:

• Dahua SG402020/SG4010-2F Uplinks: converts Gigabit SFP ports to 20km fibre.

• Remote Ruijie APs: RG-RAP72 (2.5G) → fibre → central backbone.

• Long distance CCTV: NVR → remote cameras without loss of 4K quality.
