Converter GVT-2003 10/100/1000T-IEEE 802.3x Flow

Main Features

• Gigabit Conversion: auto-negotiation RJ45 10/100/1000Base-T (full/half duplex) to single-mode fiber 1000Base-LX/ST, 1310 nm, up to 20 km range.

• Flow Control: full IEEE 802.3x, 9K Jumbo Frames, store-and-forward switching for efficient traffic in networks with scanners or RFID.

• Advanced LFP Functions: Link Fault Pass-through (LFP), Link Loss Carry Forward (LLCF), and Link Loss Return (LLR) via DIP switches for bidirectional fault diagnosis.

• Auto-MDI/MDIX: plug-and-play connection on UTP CAT5e/6 port, LED indicators for power/link/FX/TX for immediate visual diagnosis.

• External Power Supply: DC 12V (adapter included), max power consumption 5 W, compact design 71 x 94 x 26 mm, weight 200 g black.

• Industrial Temperature Range: -10°C to +55°C operating, -40°C to +70°C storage, 5-90% RH non-condensing for harsh environments.

• Modular Compatibility: standalone or integrated into a CVH-2000 chassis (14 slots), CE/FCC certifications for centralized rack mounting.

• Supported Standards: IEEE 802.3/z/ab/u, ideal for copper to fiber migration in large logistics data infrastructures.
