Allnet ALL-MC109-SFP+ VDSL2 / G.fast Modem (4038816147387)
The Allnet ALL-MC109-SFP+ is a professional-grade high-speed bridge modem designed to bridge the gap between fiber optic backbones and existing copper infrastructure. It is a versatile solution supporting VDSL2 standards (up to profile 35b) and G.fast (up to 212MHz profile), enabling symmetrical or asymmetrical data rates up to 1Gbps over standard telephone lines. The main feature of this model is its SFP+ slot, which provides a high-speed 10 Gbps uplink to your network switch or router, ensuring no bandwidth bottlenecks. Housed in a compact and durable metal enclosure, the device is designed for reliability in commercial and industrial environments. It operates as a transparent bridge, making it an ideal choice for distributing high-speed internet in hotels, apartment complexes (MDUs), or office buildings without the need for costly rewiring.
Technical Specifications
* Interface: 1x 10G SFP+ Slot, 1x RJ45 (VDSL2 / G.fast Port)
* Supported Standards: G.fast (ITU-T G.9700/9701), VDSL2 (Profiles 8a, 12a, 17a, 30a, 35b)
* Maximum Data Rate: Up to 1 Gbps (G.fast) / Up to 300 Mbps (VDSL2 35b)
* Chipset: Metanoia MT-G2421
* Management: Web-based GUI, Telnet, Console, SNMP
* Operating Mode: Bridge mode (transparent)
* Power Input: 12V DC (via included adapter)
* Material: Metal enclosure
* Mounting: Desk or wall mount
* Dimensions: 140 x 110 x 28 mm
Main Features
* Hybrid Copper/Fiber Connectivity: Combines the speed of a 10G SFP+ fiber interface with the reach of G.fast/VDSL2 copper technology, making it the perfect "last mile" solution.
* G.fast & 35b Support: Future-proof compatibility with the latest high-speed copper standards, allowing users to achieve fiber-like speeds over short copper lines.
* Managed Infrastructure: Includes a robust management interface to monitor line quality, signal-to-noise ratio (SNR) reports, and configure VLANs for secure data separation.
* Industrial Reliability: The sturdy metal enclosure ensures excellent heat dissipation and shielding, guaranteeing stable 24/7 operation in server rooms or distribution boxes.
* Low Latency Bridge: As a dedicated bridge modem, it ensures minimal packet delay, making it ideal for bandwidth-intensive applications such as VoIP, 4K streaming, and professional VPN tunnels.
