The UNI-T UT18C is a compact and versatile digital multimeter designed for basic electrical testing. It measures AC/DC voltage, resistance, capacitance, frequency, and includes diode and continuity test functions. With a CAT II 600V safety rating, it is suitable for household and light industrial use.
Featuring a clear LCD display and simple rotary switch operation, the UT18C is easy to use for both professionals and DIY enthusiasts. Its compact size and included test leads make it portable and convenient for on-the-go troubleshooting. The meter is powered by a 9V battery (included) and offers auto power-off to conserve energy.
| Brand | UNI-T |
| Model | UT18C |
| Type | Digital Multimeter |
| DC Voltage | 200mV/2V/20V/200V/600V ±0.5% |
| AC Voltage | 200V/600V ±1.2% |
| Resistance | 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/40MΩ ±0.8% |
| Capacitance | 20nF/200nF/2µF/20µF/100µF ±4% |
| Frequency | 2kHz/20kHz/200kHz/2MHz/10MHz ±1.5% |
| Diode Test | Yes |
| Continuity Test | Yes (buzzer) |
| Display | LCD, 1999 counts |
| Safety Rating | CAT II 600V |
| Power Supply | 9V battery (6F22) |
| Dimensions | 130 x 75 x 35 mm |
| Weight | Approx. 180g (including battery) |
