Product Description
Snom SP800. Voice codecs: CNG, G.711alaw, G.711ulaw, G.722, G.723.1, G.726, G.729, OPUS, PLC, VAD. Supported operating systems: Linux. VoIP protocols: SIPS (SIP over TLS), SRTP, SRTCP. Supported network protocols: IPv4 / IPv6 (dual stack), DHCP, NTP, LDAP, LLDP-MED, HTTP, TFTP, L2TP, TLS V1.3, HTTPS, IEEE..., Management protocols: TR-069, TR-069 Annex G (formerly TR-111), TR-369 (USP), uaCSTA over SIP, CSTA over HTTP(S). Supported security algorithms: HTTPS. Power supply: AC, DC, PoE, AC input voltage: 100-240 V, AC input frequency: 50/60 Hz. Width: 110 mm, Depth: 110 mm, Height: 30.2 mm
Ports and Interfaces
Ethernet LAN ports (RJ-45): 2
Number of USB 2.0 ports: 2
Weight and dimensions
Width: 110 mm
Depth: 110 mm
Height: 30.2 mm
Weight: 145 g
Power Control
Power supply: AC, DC, PoE
AC input voltage: 100-240 V
AC input frequency: 50/60 Hz
Output voltage: 5 V
Output current: 2 A
Operating Conditions
Operating temperature: 0 - 35°C
Storage temperature: -10 - 45 °C
Relative humidity range for operation: 5 - 95%
Protocols
VoIP protocols: SIPS (SIP over TLS), SRTP, SRTCP
Supported network protocols: IPv4 / IPv6 (dual stack), DHCP, NTP, LDAP, LLDP-MED, HTTP, TFTP, L2TP, TLS V1.3, HTTPS, IEEE 802.1X (EAP-TLS - RFC 5216)
Management protocols: TR-069, TR-069 Annex G (formerly TR-111), TR-369 (USP), uaCSTA over SIP, CSTA over HTTP(S)
Connectivity
DHCP client: Yes
Security
Supported security algorithms: HTTPS
Call Management
Call waiting: Yes
Features
Voice codecs: CNG, G.711alaw, G.711ulaw, G.722, G.723.1, G.726, G.729, OPUS, PLC, VAD
Reset button: Yes
LED indicators: Yes
Power LED: Yes
Supported operating systems: Linux
Device Specification
Device Dimensions
Length
13 cm
Width
12 cm
Height
5 cm
