Lab Gruppen FAD2402 Amp 2x240W 4? with Dante
- Output power: 2 x 240 W
- Low-Z (4/8 Ohm) and High-Z (70/100 V) speaker types
- Remote volume control via RJ45 port
- Comprehensive protection: thermal, overcurrent, DC, high frequency
- Versatile mounting options: rack, wall, under desk
Lab Gruppen FAD2402 Amp 2x240W 4? with Dante
The Lab Gruppen FAD2402 is a professional two-channel power amplifier delivering 240 watts per channel into 4 ohms. Designed for fixed installation applications, it features integrated Dante networked audio for seamless digital signal distribution. The amplifier employs efficient Class D technology and a universal Power Factor Corrected (PFC) power supply, ensuring reliable performance across varying mains voltages.
Housed in a compact 1U rackmount chassis, the FAD2402 offers both analog and digital inputs, with Dante providing redundant primary and secondary network ports. Front-panel indicators provide real-time monitoring of signal, clip, and fault status. The amplifier includes comprehensive protection circuitry against short circuits, thermal overload, and DC faults, making it a robust choice for commercial sound systems.
| Power Output (4Ω) | 2 x 240 W |
| Power Output (8Ω) | 2 x 120 W |
| Amplifier Class | Class D |
| Network Audio | Dante (2-port redundant) |
| Analog Inputs | 2 x balanced XLR/TRS combo |
| Analog Outputs | 2 x binding posts |
| Frequency Response | 20 Hz – 20 kHz (±0.5 dB) |
| Signal-to-Noise Ratio | > 108 dB (A-weighted) |
| THD+N | < 0.05% (20 Hz – 20 kHz, 1 dB below rated power) |
| Power Supply | Universal PFC, 90-264 V AC, 50/60 Hz |
| Dimensions (W x H x D) | 483 x 44 x 300 mm (19" x 1.73" x 11.8") |
| Weight | 4.5 kg (9.9 lbs) |
-
