Switch 16x GE GEP-2021 2xGE 2xGSFP 19" 270W 16xPoE+

Description

LevelOne GEP-2021 Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

LevelOne GEP-2021, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rackmount, 1U

Key product points

Unmanaged

Number of basic RJ-45 Ethernet switching ports: 20

MAC Address Table: 8000 entries

1U Rack Mount Stackable

Power over Ethernet (PoE)

Management Features

Switch Type: Unmanaged

Ports and Interfaces

Number of basic RJ-45 Ethernet switching ports: 20

Basic RJ-45 Ethernet switching ports: Gigabit Ethernet (10/100/1000)

Number of Fast Ethernet (copper) ports: 16

Gigabit Ethernet (copper), number of ports: 2

Number of SFP module slots: 2

Connection

Network standards: IEEE 802.1ab, IEEE 802.1af, IEEE 802.3, IEEE 802.3at, IEEE 802.3u, IEEE 802.3z

10G Support: No

VLAN Support: Yes

Optical fiber

Transmission distance (max.): 0.25 km

Data transmission

MAC Address Table: 8000 entries

Packet buffer: 29.8 MB

Design

Rack mount: Yes

Stackable: Yes

Form factor: 1U

Product color: Black

LED indicators: Yes

Performance

Built-in processor: Yes

Processor model: Realtek RTL8382L

Flash Memory: 4 MB

MTBF (PoE): 250,000 h

Power control

AC input voltage: 100 - 240 V

AC input frequency: 50 - 60 Hz

Overload protection: Yes

Overvoltage protection voltage: 6 kV

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes

Number of Power over Ethernet (PoE) ports: 16

Power per Power over Ethernet (PoE) port: 15.4 W

Power over Ethernet (PoE) Budget: 270 W

Environmental conditions

Operating temperature range: -10 - 85°C

Storage temperature range: -40 - 90 °C

Relative humidity range for operation: 0 - 90%

Heat dissipation: 86,435 BTU/h

Weight and dimensions

Width: 285 mm

Depth: 442 mm

Height: 44 mm

Weight: 4 kg
