CS-H9-70HG Multifunction CCTV Tester
- 7-inch 1024x600 LCD touchscreen display
- 4K HDMI input with H.265/H.264 video decoding
- PTZ control via RS232/RS485 with multiple protocols
- PoE (Power over Ethernet) output up to 48V/24W
- Cable tracing, continuity test, and network cable diagnosis
CS-H9-70HG Multifunction CCTV Tester
The CS-H9-70HG is a professional all-in-one CCTV tester designed for security system installers and maintenance technicians. It features a 7-inch high-resolution LCD touchscreen, 4K HDMI input for testing IP cameras, and comprehensive PTZ control via RS232/RS485. The built-in PoE output powers cameras directly, while the cable tracing and network testing functions simplify installation and troubleshooting.
With support for H.265/H.264 video decoding, the tester can display live video from analog and IP cameras. It includes a digital multimeter for voltage measurement, a network cable tester, and a tone generator for cable identification. The device runs on a rechargeable lithium battery, providing hours of field operation. Its rugged design and intuitive interface make it an indispensable tool for CCTV professionals.
| Display | 7-inch TFT LCD, 1024x600, capacitive touch |
| Video Input | HDMI (4K@30fps), CVBS, IP camera (ONVIF) |
| Video Decoding | H.265, H.264, MPEG-4, MJPEG |
| PTZ Control | RS232/RS485, Pelco-D/P, Samsung, etc. |
| PoE Output | 48V/24W, IEEE 802.3af/at |
| Cable Testing | UTP/STP cable tracing, continuity, length measurement |
| Network Tools | IP scanner, ping, port detection, DHCP |
| Multimeter | AC/DC voltage, resistance, continuity |
| Battery | 7.4V/5000mAh rechargeable Li-ion |
| Dimensions | 240 x 160 x 50 mm |
| Weight | 0.9 kg |
-
