Phanteks D30 PWM DRGB Reverse 120mm White

Reference: PH-F120D30R_DRGB_PWM_WT01
EAN: 0886523003045
Condition: New
Price: €42.81
VAT included
Without tax: €35.38
  • Size: 120mm x 120mm x 30mm
  • Speed: 200-2000 RPM (PWM)
  • Airflow: Up to 64.3 CFM
  • Noise: Up to 30.2 dB(A)
  • Lighting: Dual DRGB zones (frame & blades)
Share


Buy it now and receive it between Thu 8 and Mon 12 with GLS / UPS / DHL €5.99

  • Versatile high-end fan in white with striking ARGB lighting
  • High efficiency PWM for use in cases or on radiators
  • 30 mm in depth and aerodynamic fan blades for extra cooling
  • Connect up to four fans with clips for easy daisy-chaining
  • Available in regular or reversed models to hide spokes and hub stickers
  • Includes screw covers for clean builds

The Features of the PHANTEKS D30-120 Fan in Detail

The PHANTEKS D30-120 PWM D-RGB fans are designed to provide high airflow and static pressure. Thanks to their depth of 30 mm and powerful hydrodynamic PWM motor and aerodynamic blades, they can used to cool your case with restrictive mesh and dust filters or be put on radiators. Furthermore, they provide extensive daisy-chaining capabilities without cable clutter. You can clip up to four of them together, using just one cable to connect to your motherboard for PWM and ARGB signals.

Available in regular and reversed airflow modes, you can choose the model you need, hiding unsightly hub stickers and spokes, avoiding obstruction of the integrated D-RGB lighting, enhanced by the reflecting blades, and keeping your build immaculate. This version runs in reversed mode, moving air from the rear to the front and into the case.

The fans can be connected by two clips on the sides of the fan, one of which passes the power from the first fan through a total of four. This reduces cable clutter, just the first fan needs to be connected to your PHANTEKS controller, via a 4-pin PWM and 3-pin D-RGB JST cable. A D-RGB to 3-pin ARGB adapter cable is provided to connect directly to your motherboard.

Technical Details:

  • Dimensions: 120 x 120 x 30 mm (W x D x H)
  • Weight: 200 g
  • Colour: White
  • Material: Plastic (frame, rotor)
  • Bearing: Hydrodynamic
  • Mode: Reversed (rear to front airflow)
  • Specs:
    Speed: max. 2,000 rpm
    Airflow: max. 109.24 m³/h
    Static pressure: max. 3.01 mmH2O
    Volume: max. 30.2 dB(A)
    Current: max. 0.20 A
    Operating voltage: 12 V
  • Connections:
    4-pin PWM
    3-pin JST D-RGB
  • Cable length: 100 mm + 500 mm extension cable
  • Scope of delivery:
    1x D30-120 fan
    1x 4-pin and 3-pin extension cable
    1x Corner Clip Cable
    1x Bridge Clip Connector
    3x Corner Clip
    1x Bridge Clip
    2x Bridge Screw Cover
    2x Corner Screw Cover L
    2x Corner Screw Cover R
    4x Fan screws
    4x Radiator screws
    D-RGB motherboard adapter

  • Brand
  • Reference
    PH-F120D30R_DRGB_PWM_WT01
  • In stock
    15 Items
  • Condition
    New
  • EAN13
    0886523003045
  • MPN
    PH-F120D30R_DRGB_PWM_WT01

  • Color
    White

Brand Phanteks
Country USA
Address of origin 16720 Chestnut Street, Unit C City of Industry, CA 91748
EU responsible person Phanteks Europe B.V.
Address Penningweg 48, Almere, Netherlands, 1333MC
Email [email protected]
Phone 31365159666
