Green Cell EVGC021A2250 electric vehicle charging station Gray Aluminum Wall 3 LED built-in display

€581.68
without tax €581.68
EVGC021A2250
5904326374652
New product
Out-of-Stock
Charging electric vehicles > AC charging stations - LPEGCESTL0003 - Green Cell EVGC021A2250 electric vehicle charging station Gray Aluminum Wall 3 LED built-in display Read more...

  •   Up to 3 years warranty
  •   100% secure payment
  •   14 days return
Whatsapp Share with your friends
Characteristics
Certification
IEC 62196, IEC 62752, IEC 60309, EN 300 220-1/2, EN 300 328, EN 301 489-1/17, EN 301 489-1/3, EN 301 489-1/52, EN 301 511
IP Code (International Protection)
IP54
Vehicle loading standard
Mode 3
Feeding
Alternating current
Wifi
Yeah
Mechanical Impact Protection Code
IK10
Continuous residual current control
Yeah
overcurrent protection
Yeah
Upgradeable firmware
Yeah
Vehicle connection
Type 2
Weight and measurements
Depth
73mm
Charging cable length
5m
Height
338mm
Broad
211mm
Weight
5.51kg
Power control
Maximum charging power
22000W
Maximum operating power (three-phase)
22kW
Maximum operating current per phase
32A
Supported three-phase output voltage
400V
Number of phases
3
Minimum operating power (single phase)
1.4kW
Maximum operating current (three phase)
32A
Maximum operating power (single phase)
7.2kW
Compatible single phase output voltage
230V
Design
Shell color
Grey
Integrated charging cable
Yeah
Mounting type
Wall
Housing material
Aluminum
Built-in display
Yeah
LED indicators
Error, Load, Power, Activity, Failure
Integrated energy meter
Yeah
Display technology
LED
Wire color
Black
Technical details
Warranty period
2 years)
Brand
Green Cell
Country
Poland
Origin Address
ul. rtm. Witolda Pileckiego 8, 32-050 Skawina
Entity UE
CSG S.A.
Address
ul. rtm. Witolda Pileckiego 8, 32-050 Skawina
Email
support@greencell.global
Phone
+44 870 495 8021
