Cougar CFV235 Mesh Vision Black
The Cougar CFV235 Mesh Vision Black is a Midi Tower PC case designed for gamers and builders who want a high-airflow chassis with a built-in display. Its mesh front panel and tempered glass side window combine cooling performance with a clean, modern look. The integrated 9.16" LCD screen (1920 x 462 pixels) adds a unique visual element to your setup.
Inside, the case supports ATX, CEB, micro ATX, and Mini-ITX motherboards, giving you flexibility for different build sizes. It comes with two 160 mm front fans, one 120 mm rear fan, and three 120 mm bottom fans pre-installed, so you get strong out-of-the-box airflow. The case also supports liquid cooling and includes dust filters and cable management features.
With a maximum CPU cooler height of 17.5 cm, graphics card length of 40 cm, and PSU length of 20 cm, the CFV235 Mesh Vision Black accommodates many high-performance components. The front I/O includes two USB 3.2 Gen 1 Type-A ports, one USB 3.2 Gen 2x2 Type-C port, and a combo audio jack.
Características principales
- Midi Tower form factor with mesh front and tempered glass side panel
- Built-in 9.16" LCD display with 1920 x 462 pixel resolution
- Supports ATX, CEB, micro ATX, and Mini-ITX motherboards
- Pre-installed fans: 2x 160 mm front, 1x 120 mm rear, 3x 120 mm bottom
- 7 expansion slots, 2x 2.5" bays, and 2x 3.5" bays
- USB 3.2 Gen 1 Type-A x2, USB 3.2 Gen 2x2 Type-C x1, and audio combo jack
- Dust filters, cable management, and RGB lighting control button
Especificaciones
| Form factor | Midi Tower |
| Type | PC |
| Product colour | Black |
| Material | Glass, Steel |
| Supported motherboard form factors | ATX, CEB, micro ATX, Mini-ITX |
| Number of 3.5" bays | 2 |
| Number of 2.5" bays | 2 |
| Number of expansion slots | 7 |
| Side window | Yes |
| Suitable for | Gaming |
| Illumination | Yes |
| Illumination colour | Multi |
| Illumination location | Case fans |
| Tempered glass panel(s) | Yes |
| Dust filter | Yes |
| Cable management | Yes |
| On/off button | Yes |
| RGB lighting control button | Yes |
| Maximum CPU cooler height | 17.5 cm |
| Maximum graphics card length | 40 cm |
| Maximum PSU length | 20 cm |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Headphone/microphone combo port | Yes |
| Built-in display | Yes |
| Display type | LCD |
| Display diagonal | 23.3 cm (9.16") |
| Display resolution | 1920 x 462 pixels |
| Front fans installed | 2x 160 mm |
| Number of front fans supported (max) | 2 |
| Front fans supported diameter | 160 mm |
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported | 1 |
| Rear fans supported diameter | 120 mm |
| Number of top fans supported | 3 |
| Top fans supported diameters | 120, 140 mm |
| Bottom fans installed | 3x 120 mm |
| Number of bottom fans supported (max) | 3 |
| Bottom fans supported diameter | 120 mm |
| Liquid cooling capability | Yes |
| Width | 235 mm |
| Depth | 460 mm |
| Height | 493 mm |
Preguntas frecuentes
What is the display resolution of the built-in LCD?
The built-in LCD has a resolution of 1920 x 462 pixels and a diagonal size of 23.3 cm (9.16").
Which motherboard form factors are supported?
The case supports ATX, CEB, micro ATX, and Mini-ITX motherboards.
How many fans are pre-installed?
It comes with 2x 160 mm front fans, 1x 120 mm rear fan, and 3x 120 mm bottom fans pre-installed.
What is the maximum graphics card length?
The maximum supported graphics card length is 40 cm.
Es para ti si...
- You want a Midi Tower case with a built-in LCD screen for monitoring or customization.
- You need support for ATX, CEB, micro ATX, or Mini-ITX motherboards.
- You value high airflow with mesh front and multiple pre-installed fans.
- You plan to use a large graphics card (up to 40 cm) or a tall CPU cooler (up to 17.5 cm).
- You want modern connectivity including USB Type-C.
