Cooler Master Elite 502

Cooler Master Elite 502 Midi Tower White

Cooler Master Elite 502, Midi Tower, PC, White, ATX, EATX, ITX, micro ATX, Steel, Gaming

Key product points

Midi Tower PC Game

ATX, EATX, ITX, micro ATX

Supported hard drive sizes: 2.5, 3.5"

Number of 2.5'' bays: 2 Number of 3.5'' ports: 2

Side window Lighting Multi-panel tempered glass Dust filter

Steel

White

Design

Material: Steel

Form Factor: Midi Tower

Type: PC

Product color: White

Supported motherboard form factors: ATX, EATX, ITX, micro ATX

Number of 3.5" ports: 2

Number of 2.5'' bays: 2

Number of internal 3.5" bays: 2

Number of expansion slots: 7

Side window: Yes

Suitable for: Game

Lighting: Yes

Color lighting: Multi

Lighting location: Case fans

Tempered glass panel(s): Yes

Dust filter: Yes

Cable management: Yes

On/Off button: Yes

LED indicators: Yes

Maximum height of CPU cooler: 17 cm

Maximum graphics card length: 36 cm

Power supply

Power supply included: No

Power Supply Location: Bottom

Supported power supply form factors: ATX

Ports and Interfaces

Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports: 1

Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports: 1

Headphone/Microphone Output Combo Port: Yes

Cooling

Front fans installed: 3x 120 mm

Number of front fans supported (max.): 3

Supported front fan diameter: 120,140 mm

Number of rear fans supported: 1

Supported rear fan diameter: 120 mm

Number of top fans supported: 3

Supported upper fan diameters: 120,140 mm

Front radiator compatible sizes: 120,140,240,280,360,420 mm

Rear radiator compatible sizes: 120 mm

Compatible sizes for the upper radiator: 120,140,240,280,360 mm

Storage media

Supported hard drive sizes: 2.5, 3.5"

Weight and dimensions

Width: 230 mm

Depth: 474 mm

Height: 481 mm
